The Keysight E9300B is an E-Series average power sensor delivering accurate measurements across 10 MHz to 18 GHz with a dynamic range of 74 dB. It measures average power for all modulation formats—including W-CDMA, CDMA, TDMA, OFDM, multi-tone, and CW signals—making it bandwidth independent and suitable for high crest factor applications.
The sensor employs dual independent measurement paths: a low power path covering −30 dBm to +20 dBm and a high power path extending to +44 dBm. This architecture automatically selects the optimal range for each measurement, eliminating manual switching. A Type-N male connector interfaces with compatible Keysight power meters.
– Technical Specifications
• Frequency Range: 10 MHz to 18 GHz
• Power Range: −30 dBm to +44 dBm
• Dynamic Range: 74 dB
• Low Power Path: −30 dBm to +20 dBm
• High Power Path: +20 dBm to +44 dBm
• Maximum Average Power: +25 dBm (320 mW)
• Peak Power Handling: +33 dBm (2 Watts) for durations < 10 microseconds
• SWR: < 1.20 (10 MHz to 18 GHz at 25°C ± 10°C)
• Connector: Type-N male
• Operating Temperature: 0°C to 55°C
– Key Features
• Dual-path design automatically optimizes measurement accuracy across the full 74 dB dynamic range
• EEPROM-stored calibration factors, linearity, and temperature compensation data enable comprehensive error correction
• Temperature compensation minimizes measurement drift over the operating range
• NIST-traceable measurements following proper calibration
• One-year calibration cycle recommended
– Modulation Support
Measures average power for all modulation formats, including complex digital modulation schemes and signals with high crest factors. Bandwidth independent operation enables accurate readings across diverse signal types.
– Compatibility & Integration
Designed for Keysight EPM, EPM-P, and P-Series power meters:
• EPM Series: N1913A, N1914A, E4418B, E4419B
• EPM-P Series: E4416A, E4417A
• P-Series: N1911A, N1912A
