Agilent / Keysight E9322A E-Series Peak and Average Power Sensor, 50 MHz to 6 GHz

The Keysight E9322A E-Series Peak and Average Power Sensor delivers precision RF and microwave power measurements across 50 MHz to 6 GHz. This sensor simultaneously captures peak and average power data, enabling detailed characterization of modulated signals through time-gated measurement modes and peak-to-average ratio analysis. With an 83 dB dynamic range, ±0.21 dB accuracy, and VSWR below 1.5:1, the E9322A provides reliable performance across wireless communications, radar, electronic warfare, and general RF/microwave test environments.

– Technical Specifications

• Frequency Range: 50 MHz to 6 GHz
• Measurement Types: Peak and average power; time-gated peak, average, and peak-to-average ratio
• Power Range (Normal Mode): −45 dBm to +20 dBm
• Power Range (Average Only Mode): −65 dBm to +20 dBm
• Maximum Input Power: +23 dBm average; +30 dBm peak (< 10 µsec duration)
• Dynamic Range: 83 dB (general); 70 dB normal mode; 85 dB average-only mode
• Accuracy: ±0.21 dB
• Video Bandwidth: 1.5 MHz
• VSWR: < 1.5:1
• Output Interface: Precision Type-N male connector
• Data Rate: Up to 1000 corrected readings per second via GPIB
• Power Supply: 15 VDC to 24 VDC
• Operating Temperature: 0°C to 55°C
• Dimensions: 198 mm × 43 mm × 43 mm
• Weight: 2.27 kg

– Key Features

• Built-in EEPROM calibration factors with linearity, temperature, and bandwidth correction
• Dual measurement modes for average-only or simultaneous peak/average operation
• Low VSWR across full frequency range
• High-speed GPIB communication for automated test sequences

– Typical Applications

• Wireless communication system characterization (Bluetooth, CDMA, TDMA)
• Radar and electronic warfare system validation
• Modulated signal analysis requiring peak and average power differentiation
• Research and development of RF/microwave subsystems

– Compatibility & Integration

The E9322A integrates with Keysight power meters including the EPM-P series (E4416A/E4417A), P-series (N1911A/N1912A), and EPM series (N1913A/N1914A). Connection requires E9288A, B, or C sensor cables.
