Agilent / Keysight E9323A E-Series Peak and Average Power Sensor, 50 MHz to 6 GHz

The Agilent/Keysight E9323A is a peak and average power sensor for RF and microwave measurements from 50 MHz to 6 GHz. It delivers simultaneous peak, average, and time-domain power characterization across a dynamic range of -60 dBm to +20 dBm, with dual measurement paths optimized for different signal conditions. The normal measurement path handles peak, average, and time-related metrics across -40 dBm to +20 dBm. The average-only path extends low-level sensitivity to -60 dBm, ideal for complex modulated signals below -20 dBm or true average power measurement. A 5 MHz video bandwidth makes this sensor particularly suited for W-CDMA and cdma2000 characterization.

– Technical Specifications

• Frequency Range: 50 MHz to 6 GHz
• Video Bandwidth: 5 MHz
• Power Range: -60 dBm to +20 dBm (1 nW to 100 mW)
• Normal Mode Power Range: -40 dBm to +20 dBm
• Average-Only Mode Power Range: -60 dBm to +20 dBm
• Maximum Average Power: +23 dBm
• Maximum Peak Power: +30 dBm (duration < 10 µsec)
• Measurement Speed: Up to 1000 corrected readings per second via GPIB
• Connector: Precision Type-N (Male)
• Dimensions: 150 mm × 38 mm × 30 mm (H × W × L)
• Weight: 0.2 kg net; 0.55 kg shipping

– Key Features

• Dual-path architecture for peak, average, and time-domain measurements
• Wide dynamic range with separate sensitivity modes for low-level signals
• On-board EEPROM stores calibration factors, linearity, temperature, and bandwidth compensation data
• Fast measurement acquisition via GPIB interface

– Typical Applications

• W-CDMA and cdma2000 power characterization
• Wireless communication testing
• Radar system validation
• Modulated signal measurement and analysis

– Compatibility & Integration

• EPM-P Series power meters (E4416A/17A)
• P-Series power meters (N1911A/12A)
• GPIB-connected measurement systems
