Agilent/Keysight M9217A

The Keysight M9217A is a PXIe isolated digitizer module that delivers simultaneous high-resolution voltage acquisition across two independent channels within automated test systems. Each channel features a dedicated 16-bit ADC, enabling true parallel sampling without cross-talk or signal degradation. The module accepts input voltages up to ±256 V across a fully configurable range (±250 mV to ±256 V), eliminating the need for external signal conditioning in high-voltage applications. Built-in peak voltage protection rated to 400 V safeguards measurement integrity during transient events. A floating differential measurement capability of ±40 V extends measurement flexibility for multi-point acquisitions.

– Technical Specifications

• Form Factor: Single-slot PXIe module
• Channels: 2 isolated input channels with simultaneous sampling
• ADC Resolution: 16 bits
• Maximum Sample Rate: 20 MSa/s
• Bandwidth: 20 MHz
• Memory Depth: 32 MSa/Ch with segmented memory up to 1024 records
• Input Voltage Range: ±250 mV to ±256 V (configurable)
• Peak Voltage Protection: 400 V
• Floating Voltage: ±40 V for differential waveform acquisition
• Isolation Voltage (Low to Chassis): +40 V

– Key Features

• Dual isolated channels eliminate inter-channel noise and enable simultaneous acquisition of disparate signal domains
• ±256 V input range reduces or eliminates signal attenuation requirements
• 400 V peak protection handles transient overvoltage events in automotive and industrial switching environments
• 32 MSa/Ch memory supports extended capture windows and high-speed transient analysis
• Segmented acquisition mode (up to 1024 records) enables multi-trigger event capture within a single acquisition window
• Multiple trigger sources: immediate, external (SMD), PXI TTL, PXI Star, DSTARB, software command, and channel-based edge detection with configurable hysteresis

– Typical Applications

High-voltage signal analysis in automotive powertrain and battery management systems; mechatronic motor drive characterization; aerospace and defense power supply transient monitoring; multi-point industrial machinery diagnostics.

– Compatibility & Integration

Installs in any PXIe or PXI-H chassis peripheral slot. Supported through IVI-COM, IVI-C, and LabVIEW G drivers. Software environments include LabVIEW, LabWindows/CVI, and Microsoft C/C++, C#, VB.NET. Keysight IO Libraries Suite and Soft Front Panel provided.
