Agilent/Keysight MSO7034B

The Agilent/Keysight MSO7034B is a mixed-signal oscilloscope that captures and analyzes both analog and digital signals simultaneously across 20 total channels. Its 350 MHz bandwidth, dual-channel architecture—4 analog and 16 digital channels—and deep acquisition memory enable engineers to debug complex embedded systems, validate signal integrity, and decode serial protocols in real time.

– Technical Specifications

• Bandwidth: 350 MHz
• Analog Channels: 4 at up to 2 GSa/s sample rate
• Digital Channels: 16 at up to 16 GSa/s sample rate
• Memory Depth: 8 Mpts standard (MegaZoom III), expandable to 32 Mpts on analog channels
• Waveform Update Rate: Up to 100,000 waveforms/sec
• Display: 12.1-inch XGA color (1024 × 768), 256 intensity levels
• Vertical Resolution: 8 bits
• Input Impedance: 1 MΩ ± 1% || 15 pF ± 3 pF (analog); 100 kΩ ± 2% || 3.3 pF ± 1.5 pF (digital)
• Maximum Input Voltage: 300 Vrms CAT II (analog); ±15 V (digital)

– Key Features

• Hardware-accelerated serial protocol triggering and decoding: I²C, SPI, CAN, LIN, RS-232/UART, USB, I²S, FlexRay, MIL-STD-1553
• Automatic search and navigate functionality for protocol data streams
• Integrated mask testing for design validation
• Segmented memory optimization for data with extended dead times
• FPGA debug capabilities
• MATLAB integration for custom measurements and user-defined filters
• Secure Environment Mode (Option SEC) clears internal non-volatile memory per NISPOM Chapter 8 requirements

– Typical Applications

• Embedded system development and troubleshooting
• Mixed-signal protocol analysis and validation
• FPGA debugging and verification
• Signal integrity testing with mask compliance
• Long-duration signal capture with responsive deep memory

– Compatibility & Integration

MATLAB software support enables custom analysis routines and instrument automation. Serial protocol support spans industrial, automotive, and aerospace standards.
