Agilent/Keysight MSOX2014A

The Keysight MSOX2014A is a mixed-signal oscilloscope from the InfiniiVision 2000 X-Series that captures and analyzes analog and digital signals simultaneously. It combines 100 MHz bandwidth, four analog channels, and eight digital channels in a single instrument. The 1 Mpts acquisition memory per channel and up to 200,000 waveforms/sec update rate deliver detailed transient visibility. An 8.5-inch WVGA color display and USB host/device connectivity support field analysis and data transfer.

– Technical Specifications

• Bandwidth: 100 MHz
• Analog Channels: 4
• Digital Channels: 8
• Sampling Rate: Up to 2 GSa/s (half-channel); 1 GSa/s per channel
• Acquisition Memory: 1 Mpts per channel
• Waveform Update Rate: Up to 200,000 waveforms/sec
• Vertical Resolution: 8-bit
• Display: 8.5-inch WVGA color
• Dimensions: Approximately 15 inches wide, less than 6 inches deep
• Weight: Approximately 8.5 pounds

– Key Features

• Waveform math and FFT analysis
• Edge, pulse width, pattern, rise/fall time, runt, setup & hold, video, and USB triggering
• Multi-language help system (English, Japanese, simplified and traditional Chinese, Korean, German, French, Spanish, Russian, Portuguese, Thai, Polish, Italian)
• Four 150 MHz 10:1 passive probes (N2862B) included
• 8-channel logic probe kit (N2755-60001) included
• Certificate of Calibration and documentation CD
• 5-year standard warranty

– Optional Enhancements

• Serial protocol triggering and decode: CAN/LIN, I2C/SPI, UART/RS232
• 20 MHz function generator
• Digital voltmeter
• LAN connectivity
• VGA output
• GPIB interface

– Typical Applications

Designed for engineers and technicians requiring simultaneous analog and digital signal acquisition in embedded systems development, digital design verification, mixed-signal troubleshooting, and protocol-level analysis with optional decode capabilities.
