The Keysight MSOX3102G is a 1 GHz mixed-signal oscilloscope delivering 2 analog channels, 16 digital channels, and 5 GSa/s per-channel sampling. This 7-in-1 instrument combines oscilloscope, logic analyzer, protocol analyzer, Bode plot frequency response analyzer, 20 MHz arbitrary waveform generator, 3-digit voltmeter, and 8-digit counter/totalizer in a compact 15 × 8 × 5.6 inch form factor weighing 9.3 lbs.
Acquisition performance reaches 1,000,000 waveforms per second with 8-bit vertical resolution and up to 4 Mpts memory depth. The 8.5-inch capacitive touchscreen provides intuitive control alongside traditional front-panel buttons and knobs. Zone Touch triggering, edge triggering, pattern triggering, and protocol-based triggering isolate complex signal anomalies. Standard features include mask and measurement limit testing plus waveform and measurement histograms.
Protocol support spans I2C, SPI, UART, I2S, and USB PD trigger and decode. Connectivity includes LAN, VGA, USB host, and USB device ports. Included accessories are one N2843A 500 MHz passive probe (10:1 attenuation) per analog channel and the N2756A 16-channel MSO cable. The D3000GENB embedded software package and PathWave BenchVue Oscilloscope Software (BV00) complete the measurement environment.
– Technical Specifications
• Analog Bandwidth: 1 GHz
• Analog Channels: 2
• Digital Channels: 16
• Sample Rate: 5 GSa/s per channel
• Memory Depth: Up to 4 Mpts
• Waveform Update Rate: 1,000,000 waveforms/sec
• Vertical Resolution: 8 bits
• Arbitrary Waveform Generator: 20 MHz
– Key Features
• 7-in-1 integrated instrument: oscilloscope, logic analyzer, protocol analyzer, frequency response analyzer, waveform generator, voltmeter, and counter/totalizer
• Zone Touch triggering for efficient glitch capture
• Mask and measurement limit testing
• Waveform and measurement histograms
• Protocol trigger and decode: I2C, SPI, UART, I2S, USB PD
• 8.5-inch capacitive touchscreen display
• Small form factor: 9.3 lbs
– Typical Applications
• Embedded systems debugging and signal validation
• Mixed-signal design verification
• Protocol analysis and compliance testing
• Frequency response characterization
– Compatibility & Integration
• Connectivity: LAN, VGA, USB host, USB device
• Included probes: N2843A (500 MHz, 10:1)
• Digital cable: N2756A 16-channel MSO
• Software: D3000GENB embedded package; PathWave BenchVue Oscilloscope (BV00)
