Agilent/Keysight N1501A

The Keysight N1501A Dielectric Probe Kit measures complex permittivity and determines intrinsic electromagnetic properties of dielectric materials across frequency ranges up to 50 GHz. The system integrates with Keysight network or impedance analyzers and the N1500A Materials Measurement Suite software to deliver dielectric constant, loss factor, loss tangent, and Cole-Cole analysis in real time. Non-destructive measurement capability supports liquids, semi-solids, and flat-surfaced solids in R&D, incoming inspection, process monitoring, and quality assurance workflows.

– Technical Specifications

• Frequency range: 10 MHz to 50 GHz (analyzer and probe dependent); 200 MHz to 50 GHz (probe option dependent)
• Measurement parameters: Complex permittivity, dielectric constant, dielectric loss factor, loss tangent, Cole-Cole
• Operating temperature: −40 °C to +200 °C
• Probe aperture: 3.5 mm (available on select probe options)
• Non-destructive, real-time measurement capability

– Key Features

• Rugged sealed probe design with glass-to-metal hermetic seal resists corrosive and abrasive chemicals
• Autoclavable performance probe for sterilization in food, medical, and chemical applications
• Slim-form probe geometry permits insertion into small apertures, fermentation tanks, and reaction chambers
• Large flange accommodates flat-surfaced solid materials, liquids, and semi-solids
• Automated electronic calibration refresh reduces cable instability and system drift before each measurement
• Optional ECal bracket (N1501A Option 004) supports electronic calibration refresh
• Performance probe kit includes calibration short
• Three probe options: Performance Probe, Slim Form Probe, and High Temperature Probe
• Slim form probe kit features sealed slim form holder adapting 2.2 mm outer diameter to 10 mm inner diameter bracket

– Typical Applications

• RF and microwave component characterization
• Biomass and bulk density measurement
• Bacterial content monitoring
• Chemical concentration analysis
• In-process analytical technology implementation

– Compatibility & Integration

• Requires Keysight network analyzer or impedance analyzer
• Integrates with N1500A Materials Measurement Suite software
