Agilent / Keysight N3303A 250 Watt Electronic Load Module

The N3303A is a 250 W electronic load module engineered for integration into Agilent/Keysight N3300A or N3301A mainframes. It delivers fast, accurate performance across DC power supply, DC-to-DC converter, and battery testing applications in high-volume ATE environments. The module accepts 0–240 V at 0–10 A with full stability down to zero volts and minimum operating voltage of 1.2 V at full scale current.

– Technical Specifications

Input Ratings
• Voltage: 0 V to 240 V
• Current: 0 A to 10 A
• Maximum Power: 250 W (derated linearly to 75% at 55°C)
• Minimum Operating Voltage @ Full Scale Current: 1.2 V

Operating Modes
• Constant Current (CC): 1 A to 10 A with 8 mA regulation; accuracy 0.1% + 4 mA (low range) or 0.1% + 7.5 mA (high range)
• Constant Voltage (CV): 24 V to 240 V with 10 mV regulation; accuracy 0.1% + 10 mV (low) or 0.1% + 40 mV (high)
• Constant Resistance (CR): 0.2 Ω to 4800 Ω across three ranges (0.2–48 Ω, 44–480 Ω, 440–4800 Ω)

Measurement System
• 16-bit resolution for voltage, current, and power
• Voltage Measurement: 0.1% + 10 mV (24 V range) or 0.1% + 40 mV (240 V range)
• Current Measurement: 0.1% + 4 mA (1 A range) or 0.1% + 7.5 mA (10 A range)
• Power Measurement: 0.1% + 1.2 W
• Waveform digitization with 4096-point buffers for simultaneous voltage and current capture; programmable sampling rate and window; RMS, max, and min analysis functions

– Key Features

• Modular single-slot design for flexible multi-source testing
• SCPI programming with GPIB and RS-232 remote control
• Front panel manual operation supported
• Analog programming ports available

– Compatibility & Integration

The N3303A occupies one slot in the N3300A or N3301A electronic load mainframe, enabling scalable test configurations for simultaneous testing of multiple power sources.
