Agilent / Keysight N3304A 300 Watt Electronic Load Module

The Agilent/Keysight N3304A is a 300 W electronic load module engineered for insertion into N3300A or N3301A mainframes. It delivers precise DC load simulation across constant current, constant voltage, and constant resistance operating modes, enabling comprehensive characterization of power supplies, batteries, and regulated DC sources. The module performs simultaneous voltage and current measurements with waveform digitization to 4096 data points, capturing ripple and noise content from 20 Hz to 10 MHz for detailed power source analysis.

– Technical Specifications

• Power Rating: 300 W
• Input Voltage Range: 0 VDC to 60 VDC (Option J01 extends to 80 V)
• Input Current Range: 0 A to 60 A
• Constant Current Mode: 6 A (low) to 60 A (high); regulation 10 mA; accuracy 0.1% + 5 mA (low) / 0.1% + 10 mA (high)
• Constant Voltage Mode: 6–60 V (8–80 V with Option J01); regulation 10 mV; accuracy 0.1% + 3 mV (low) / 0.1% + 8 mV (high)
• Constant Resistance Mode: Four ranges from 0.033 Ω to 2600 Ω
• Measurement Accuracy: Voltage 0.05% + 3 mV (low) / 0.05% + 8 mV (high); current 0.05% + 3 mA (low) / 0.05% + 6 mA (high); power 0.1% + 0.4 W
• Minimum Operating Voltage: 1.2 V typical at full scale current; stable operation specified down to 0 V

– Key Features

• SCPI command compatibility with fast settling times
• Programmable slew rate and command sequencing (“Lists”) independent of host computer
• Configurable delays for simultaneous or sequential load transitions
• Analog, RS-232, and GPIB interfaces
• Single GPIB address control when installed in mainframe

– Typical Applications

• Power supply regulation and load characterization
• Battery discharge profiling and performance validation
• DC source stability and transient response analysis
• Ripple and noise measurement

– Compatibility & Integration

Mounted as a single-slot module within N3300A or N3301A mainframes. Net weight 2.7 kg.
