The N9029AV05 is a millimeter-wave frequency extension module that extends Keysight X-Series signal analyzers into the 140–220 GHz band. Manufactured by VDI Inc., this WR5.1 waveguide-based analyzer covers the full WRxx SAX Series capability, delivering high-sensitivity measurements with direct frequency and amplitude display on the host instrument. The module operates in two distinct modes: Standard Mode uses the signal analyzer’s multiplied LO signal for general spectrum analysis of stable CW and narrowband signals, while Block Down-Converter Mode employs a separate signal generator to downconvert wideband RF blocks to intermediate frequencies up to 20 GHz—ideal for signals with drift or complex modulation. Typical conversion loss is 12 dB.
– Technical Specifications
• Frequency Range: 140 to 220 GHz
• Waveguide Band: WR5.1
• Input Port Flange: WR5.1 (VDI precision, UG-387/UM)
• Conversion Loss: Typically 12 dB
• IF Output Frequency: 16 kHz to 2.5 GHz (standard); 16 kHz to <20 GHz (block down-converter)
• LO Input Level: 7 to 13 dBm (standard); −3 to 3 dBm (high frequency)
• Power Supply: 9V DC
– Key Features
• Dual operating modes address both narrowband analysis and wideband block downconversion
• Conversion loss correction via USB-supplied correction tables integrated into the signal analyzer
• Direct display of frequency and amplitude on compatible X-Series instruments
• Precision waveguide and connector interfaces for millimeter-wave signal integrity
– Typical Applications
• Spectrum analysis of millimeter-wave signals in the 140–220 GHz band
• Wideband communication signal characterization with block downconversion
• High-sensitivity detection of narrowband CW and stable modulated signals
• Frequency extension of laboratory and field-deployable signal analysis systems
– Compatibility & Integration
Requires Option EXM on the host X-Series signal analyzer. Compatible with Keysight N9030A/B PXA, N9020A/B MXA, N9010A/B EXA, N9040B/41B UXA, and N9038A MXE instruments. Interfaces include WR5.1 RF input, 2.92 mm LO and IF connectors.
