Agilent/Keysight SL1041B High Resolution DAQ Module

The Keysight SL1041B is a high-performance, bi-directional, regenerative Dynamic DC Emulator (DCE) designed for advanced testing applications in research, development, and manufacturing. Part of the Mid-Power Series, it integrates seamlessly with the Scienlab Charging Discovery System (CDS) to emulate EVSE or act as an electronic load for EV emulation. This system is engineered to return consumed energy to the power grid, thereby reducing energy consumption and cooling costs. The compact 3U-high package combines source and load functionalities, saving valuable rack space and integration time. The SL1041B is suitable for testing power electronic components and systems, battery emulation, and validating DC charging processes.

### Technical Specifications

* **Product Name:** Agilent/Keysight SL1041B
* **Product Series:** Scienlab Dynamic DC Emulator (DCE) Mid-Power Series
* **Form Factor:** Cabinet
* **Maximum Voltage:** 950 V DC
* **Maximum Current:**
* 100 A per unit
* Up to 300 A DC when three racks are paralleled
* **Maximum Power:**
* 50 kW per rack (fully equipped with five power stages)
* Up to 150 kW when three racks are paralleled
* **Power Stages:** Up to five per rack, utilizing the Regenerative Power System (RP7900 Series)
* **Type:** Bi-directional, regenerative DC power supply
* **Regenerative Capability:** Returns consumed energy to the power grid, reducing energy consumption and cooling costs
* **Command Processing Time:** Sub-millisecond
* **Output Speed:** Fast
* **Integration:** Seamless source and load functionality in a compact 3U-high package

### Applications

* **Power Electronics Testing:** Test power electronic components and systems for failure safety, energy efficiency, and quality.
* **Battery Emulation:** Emulate batteries using an integrated battery model.
* **EV/EVSE Emulation:**
* Act as a DC power source for EVSE emulation when used with the Scienlab Charging Discovery System (CDS).
* Act as an electronic load for EV emulation, replacing a battery pack and feeding energy back to the grid.
* **DC Charging Process Validation:** Validate DC charging processes.
* **Interoperability Testing:** Test interoperability between EV emulation (sink) and charging infrastructure (source) in conjunction with the Scienlab CDS.

### Interfaces

* **Digital Interfaces:**
* Ethernet (RJ45 socket) for interface to Charging Discovery System.
* RJ45 socket for parallel mode connection of up to three DC emulators.
* **Power Connections:**
* AC Power Supply Connection: 125 A CEE (IEC 60309) socket.
* DC Output Connection: Voltage up to 950 V, Current up to 300 A (when paralleled).
* **Optional Accessories:**
* AC input cable with 63 A CEE plug [SL1041B-01] or 125 A CEE plug [SL1041B-02].
* “Plug-in for EVSE Emulation” (SL1049A-106) when using the emulator in combination with the CDS for EVSE emulation.

### Physical and Electrical

* **Chassis:** 19-inch rack aluminum housing on wheels.
* **Integrated Components:** Circuit breaker (Siemens C20A) and RCD (Siemens 5SV3 RCCB).

### Compatibility

* **Scienlab Charging Discovery System (CDS):** Designed for integration with the Scienlab CDS for comprehensive EV/EVSE testing.
* **Parallel Operation:** Supports parallel connection of up to three SL1041B units to achieve higher power and current ratings.
