Agilent/Keysight U2022XA

The Keysight U2022XA is a USB-connected average power sensor delivering peak and average power measurements across microwave and millimeter-wave frequencies. This compact, portable instrument eliminates the need for external zeroing or calibration sources—internal DC reference and switching circuits perform both functions without disconnecting the device under test. Built-in radar and wireless presets support DME, GSM, EDGE, CDMA, WCDMA, WLAN, WiMAX, and LTE standards. External trigger input and output connectors enable precise synchronization with signal sources and DUTs via standard BNC-to-SMB cabling.

– Technical Specifications

Frequency & Power Performance
• Frequency range: 50 MHz to 40 GHz (upgradeable to 50 GHz with Option H50)
• Average power range: –45 dBm to +20 dBm
• Gated average power range: –30 dBm to +20 dBm
• Peak power range: –30 dBm to +20 dBm
• Video bandwidth: 30 MHz (selectable: High, Medium, Low, Off)
• Rise time: ≤13 ns; Fall time: ≤13 ns (at 30 MHz bandwidth)
• Real-time sampling: 80 Msamples/sec
• Measurement speed: Greater than 25,000 readings/second (fast buffer mode)

Accuracy & Calibration
• Valid for frequencies ≥500 MHz over –15 to +20 dBm and 0.5 to 40 GHz (DUT Max SWR <1.2)
• Internal zeroing and calibration without external equipment

Mechanical & Connectivity
• Connector: 2.4 mm male (Option 100)
• USB connectivity for direct computer integration

– Key Features

• No external sources required—zeroing and calibration via internal DC reference
• External trigger I/O for measurement synchronization
• BenchVue software compatibility (BV0007B Power Meter/Sensor Control and Analysis app)
• Data logging and visualization without programming
• Real-time pulse capture at 80 Msamples/sec

– Typical Applications

• Aerospace and defense power monitoring
• Wireless communication systems (LTE, WCDMA, GSM)
• WLAN and wireless networking characterization
• Manufacturing and field-test environments

– Compatibility & Integration

The U2022XA integrates with Keysight BenchVue software for measurement automation and real-time data analysis. External trigger connections enable synchronized operation with signal sources and devices under test.
