The Keysight U2031C is a USB-powered average power sensor delivering precise measurements across continuous wave and modulated signals from 9 kHz to 26.5 GHz. Operating over a dynamic range of -60 dBm to +44 dBm, it captures up to 250 readings per second and supports GSM, EDGE, WLAN, and WiMAX signal analysis. The sensor connects directly via USB 2.0 with no external power supply required, drawing approximately 170 mA—enabling multiple units to operate simultaneously without additional hubs.
Internal zeroing isolates the sensor from the device under test without disconnection or power-down, reducing test time and connector wear. Triggering capability accommodates both internal and external sources, with trace display enabling straightforward burst signal configuration. The U2031C can monitor more than 20 channels simultaneously and integrates into automated test environments via SCPI commands.
– Technical Specifications
• Frequency range: 9 kHz to 26.5 GHz (sensor option dependent)
• Dynamic range: -60 dBm to +44 dBm
• Measurement type: Average power for CW and modulated signals
• Reading speed: Up to 250 readings per second
• Current consumption: ~170 mA (USB bus-powered)
• Connector: USB 2.0 Type A to 5-pin Mini-B with locking mechanism
• Cable: 5-meter USB 2.0 compliance cable included
– Key Features
• Internal zeroing without sensor disconnection
• Internal and external trigger support
• Simultaneous monitoring of 20+ channels
• Trace display for burst signal gate and trigger level setup
• No external power supply required
– Typical Applications
• GSM, EDGE, WLAN, and WiMAX signal characterization
• Multi-channel power monitoring in production test
• Modulated and continuous-wave signal measurement
– Compatibility & Integration
Bundled with Keysight N1918A Power Analysis Manager software for basic measurements and multi-channel data analysis. Compatible with Keysight IO Library Suite, Command Expert, and PathWave VSA software. Supports SCPI control for external computer automation across Windows and Linux platforms.
