Agilent/Keysight U8201A

The Agilent/Keysight U8201A is a combo test lead kit engineered for use with Agilent and Keysight digital multimeters and DC power supplies. This accessory package delivers a full complement of connection and measurement tools—extension test leads, test probes, alligator clips, SMT grabbers, fine tips probes, and banana plugs—enabling safe, compliant operation across diverse bench and field measurement scenarios.

– Technical Specifications

The kit contains multiple component types, each rated for distinct voltage and current operating ranges:

• Test Leads: CAT III 1000 V, 15 A
• Test Probes: CAT II 1000 V, 15 A
• Alligator Clips: CAT III 1000 V, 10 A
• SMT Grabbers: CAT II 300 V, 3 A
• Fine Tips Test Probes: CAT II 300 V, 3 A
• Banana Plugs: CAT II 600 V, 10 A

– Key Features

Multiple probe and lead options support flexible connection topologies. SMT grabbers and fine-tipped probes address low-voltage circuit diagnostics and surface-mount device testing. Alligator clips and banana plugs facilitate high-current connections and repeated connections to panel terminals. Dual CAT rating structure (CAT II and CAT III) allows deployment across both high-energy industrial circuits and utility-grade measurement points.

– Typical Applications

The kit suits general-purpose electronics troubleshooting, power supply characterization, and component-level diagnostics on bench and in the field. The graduated voltage and current ratings enable transition between sensitive analog circuitry and power distribution measurements without reconfiguring lead sets.

– Compatibility & Integration

Designed primarily for the Agilent/Keysight U3606A Digital Multimeter and DC Power Supply. Compatible with broader Agilent and Keysight digital multimeter and DC power supply product families.
