Agilent/Keysight W2638A

The Agilent/Keysight W2638A is a BGA probe for accessing and analyzing LPDDR, LPDDR NVM, and mobile-DDR DRAM signals within ball grid array packages. It interposes between the DRAM and printed circuit board, enabling comprehensive state and timing measurements of DRAM buses—including DQ, DQS, and clock signals—without requiring design modifications. The probe supports both x16 (60 balls) and x32 (90 balls) package configurations at data rates up to 400 Mb/s and operates across a 1.5 GHz bandwidth.

– Technical Specifications

• Product Type: LPDDR BGA Probe
• Supported DRAM Types: LPDDR SDRAM, LPDDR NVM, Mobile-DDR DRAM
• Package Configurations: x16 (60 balls), x32 (90 balls)—all signals accessible
• Data Transfer Rate: Up to 400 Mb/s
• Bandwidth: 1.5 GHz
• Operating Temperature: 0° to +100° C
• Maximum Altitude: 4,600 m (15,000 ft)
• Humidity: Up to 50% non-condensing

– Key Features

• Buried resistor design minimizes capacitive loading and isolates signals
• Compatible with both leaded and lead-free solder finishes
• Tolerates lead-free soldering temperature profiles
• DRAM soldered to probe top side; operates at full speed without performance degradation
• S-parameter models available for de-embedding with InfiniiSim

– Typical Applications

• LPDDR/Mobile-DDR DRAM characterization and validation
• JEDEC compliance testing and signal integrity analysis
• State and timing measurements on DRAM buses in mobile and embedded systems
• Full-speed in-circuit probing without PCB design changes

– Compatibility & Integration

Logic Analyzer Connection: Interfaces via E5384A and E5826A single-ended ZIF probes to Keysight 16800 Series, 16900 Series, or U4154A AXIe-based logic analyzer module.

Oscilloscope Connection: Attaches to W2639A LPDDR scope adapter board and uses E2678A InfiniiMax socketed probe head for connection to Keysight Infiniium 80000, 9000, or 90000A Series oscilloscopes.
