The Agilent/Keysight X752C is a WR-90 waveguide directional coupler designed for precision microwave measurements across the 8.2 to 12.4 GHz band. This conventional multi-hole construction coupler delivers 10 dB nominal coupling with ±0.4 dB mean accuracy and maintains directivity better than 40 dB across its entire frequency range. Low SWR performance—1.05 maximum on the primary line and 1.15 on the auxiliary line—ensures minimal signal degradation in cascade applications.
– Technical Specifications
• Frequency Range: 8.2 to 12.4 GHz
• Product Type: Waveguide Directional Coupler
• Series: 752 Series
• Coupling Factor: 10 dB nominal
• Coupling Accuracy: ±0.4 dB (mean)
• Coupling Variation vs. Frequency: ±0.5 dB maximum
• Directivity: 40 dB minimum
• Primary Line SWR: 1.05 maximum
• Auxiliary Line SWR: 1.15 maximum
• Waveguide Interface: WR-90
• Construction: Conventional multi-hole design
– Key Features
• High directivity (>40 dB) across full operating band
• Tight coupling accuracy within ±0.4 dB
• Stable performance independent of humidity, temperature, and time
• Minimal primary line reflections with SWR of 1.05 max
– Typical Applications
• Attenuation measurements
• Reflectometer setups
• Power measurements
• Source leveling
• Network analysis
• Microwave standards measurements
– Compatibility & Integration
The X752C integrates into standard WR-90 microwave test systems. It pairs effectively with frequency sources including the Agilent 8350 and 8340 Series sweepers, and with analyzers such as the 8510 network analyzer and 8756/8757 scalar network analyzers.
