Ametek / Elgar 32V Mod. Master Power Module

The Ametek / Elgar 32V Mod. Master Power Module is a precision DC power supply component engineered for integration into AT8000A/B series modular mainframes. It delivers 32V DC at 6.25 A (200W output) with remote programmable voltage and current control, making it ideal for multi-channel test systems and industrial power applications requiring stable, configurable output. The master module supports master/slave operation—up to five slave modules can parallel with a single master to increase channel current capacity.

– Technical Specifications

• Output Voltage: 32V DC
• Output Current: 6.25 A
• Output Power: 200W
• Input Voltage: Configurable via multi-tap transformer (3-phase WYE or DELTA)
• Input Voltage Tolerance: ±10% of rated input voltage
• Frequency: 47–66 Hz
• Power Factor: 0.8 typical (50% to 100% full load, passive PFC)
• Efficiency: 85% at full power
• Idle Losses: <1.5 kW per 30 kVA rated output

– Key Features

• Programmable voltage and current with remote sense terminals for accurate output regulation at the load
• Integrated output relay and independent SCR crowbar for rapid discharge capability
• Voltage and current readback for system monitoring
• GPIB (IEEE-488) remote control interface with selectable bus address
• Master/slave configuration enables parallel operation for increased current delivery
• Air-cooled design with modular plug-in form factor
• ATE qualified—supports MATE and CIIL programming environments

– Typical Applications

Precision DC power sourcing in automated test equipment (ATE), multi-channel power distribution systems, and industrial test benches requiring stable 32V regulation with remote programmability and monitoring.

– Compatibility & Integration

Designed exclusively for AT8000A/B mainframes, which accommodate up to six power supply and/or electronic load modules per chassis. One master module is required per channel; up to five slave modules can be interconnected per master for parallel current expansion.
