Ametek / Elgar PIP9012A-1T-311 Digital / Analog Programmable Plug-In Oscillator

The Ametek/Elgar PIP9012A-1T-311 is a digital/analog programmable plug-in oscillator engineered for seamless integration into Elgar SL, SX, and DMAC II series AC power sources. This extended-range variant delivers precise waveform generation and signal conditioning via front-panel keyboard control and GPIB (IEEE 488-1978) command architecture. The unit combines manual and remote programmability to support custom test scenarios within integrated measurement systems.

– Technical Specifications

Output & Frequency Programming
• Voltage Range: 0–135 VAC (RNG0), 0–270 VAC full scale
• Voltage Resolution: 0.1 VAC; Accuracy: ±0.2% of full scale
• Frequency Range: 45 Hz to 9999 Hz (extended via Test option modification)
• Frequency Resolution: 0.01 Hz (45–99.99 Hz), 0.1 Hz (45–999.9 Hz), 1 Hz (45–5000 Hz)
• Frequency Accuracy: ±0.001% of setting; Temperature Coefficient: 0.003% per °C
• Frequency Settling: ≤1/2 cycle at new frequency
• Current Limit: 5% to 100%, 0.01 A resolution; Accuracy: ±1% FS ±1.0% of reading
• Crest Factor: 3.5:1 minimum
• Phase Angle: 0–360°, 0.5° resolution; Accuracy: ±1° (45 Hz–2 kHz), +1° per kHz above 2 kHz
• Drop-Out Programming: 1–9 cycle capability
• Total Harmonic Distortion: <1% within source range

Regulation & Stability
• Load Regulation: ±0.015% (no load to full load)
• Line Regulation: ±0.015% (±10% line variation)
• Remote Sense Regulation: ±0.015%

Measurement & Diagnostics
• Readback: Extended frequency range to 9999 Hz
• Measured Parameters: Output voltage, load current, load watts, output frequency
• Built-In Test: Continuous self-monitoring for overvoltage, open sense leads, overcurrent

Physical & Operating
• Dimensions: 7.25" × 3.5" × 8.0" (W × H × D)
• Operating Temperature: 0°C to 50°C
• Input Power: 117 VAC, ±42 VDC from AC source
• Sync Pulse Output: Available

– Key Features

• Extended frequency programming to 9999 Hz via Test option modification
• Millihertz-resolution frequency tuning (0.01 Hz steps at low frequencies)
• ±0.001% frequency accuracy with minimal temperature drift
• GPIB remote control for automated test sequences
• Phase angle control across standard audio and low-frequency ranges
• Integrated current limiting and crest factor specification
• Built-in self-test diagnostics for fault detection

– Compatibility & Integration

Designed as a direct plug-in module for Elgar AC power sources (SL, SX, DMAC II series). Accepts 117 VAC primary power and dual ±42 VDC supplies from the host unit. Compatible with IEEE 488-1978 (GPIB) instrumentation networks for multi-unit test automation.
