Amplifier Research TC2000

The Amplifier Research TC2000 is a transconductance amplifier that delivers stable, controlled current output for precision testing and measurement in laboratory environments. It excels at semiconductor device characterization and component testing through logic or analogue control inputs. The TC2000 model is optimized for resistive loads with low temperature coefficient, while the TC2001 variant accommodates inductive loads including three-phase transformers. Both units support multiple firing modes: burst firing for analogue inputs and logic firing for digital control, with the TC2001 offering adjustable delayed firing angle on the first cycle.

– Technical Specifications

• Product Type: Transconductance Amplifier
• Control Inputs: Logic or analogue inputs
• Firing Modes: Burst firing (analogue), logic firing (digital), burst firing with adjustable delayed firing angle (TC2001 only)
• Load Capability: Single three-phase, three-wire load (star or delta configuration) or two independent single-phase loads
• Supply Frequency: 50 Hz to 60 Hz
• Auxiliary Supply: 100 V to 240 V (+10%, −15%), 5 VA + fans (not required for 60 A and 75 A logic input units without PLU option)
• Power Dissipation: 2 W per ampere per switched phase
• Maximum Altitude: 2000 m
• Atmosphere: Non-explosive, non-corrosive

– Key Features

• Stable and controlled current output for demanding laboratory applications
• EMC internal filter standard on 60 A and 75 A units; optional on 100 A and 150 A units
• Thermal management with fan cooling from 100 A onwards
• Thermal switch protection for over-temperature shutdown
• Cooling configuration: single 24 VDC 5 W fan (100 A and 150 A units); dual 24 VDC 5 W fans (250 A to 500 A units)
• Compact form factor with user terminal block for control wires and optional PLU alarm relay switch

– Typical Applications

• Semiconductor device characterization
• Component testing in controlled laboratory settings
• Load control for resistive and inductive applications
• Multi-phase power distribution testing

– Compatibility & Integration

• TC2000: Resistive loads with low temperature coefficient
• TC2001: Resistive and inductive loads, including three-phase transformers
• Designed for EMC Directive compliance when integrated into complete systems
