Analogic DBS901 14-Bit Arbitrary Waveform Generator Module

The Analogic DBS901 is a 14-bit arbitrary waveform generator module designed for VXI integration into the DBS9900 carrier chassis. It delivers high-speed signal generation with 14-bit resolution at sample rates up to 100 MHz, supporting demanding applications in semiconductor testing, video and digital communications simulation, vibration testing, and R&D. The modular architecture permits two DBS901 units per VXI slot, optimizing chassis utilization and system cost.

– Technical Specifications

Waveform Generation
• Resolution: 14-bit (Two’s complement, left-justified)
• Maximum sample rate: 100 MHz
• Memory: 1 MS (DBS901) or 8 MS (DBS901LM)
• Segment length: 10 samples to 64 kS; up to 43,687 segments
• Looping: 1 to 64,000 repetitions or continuous

Signal Output
• Full-scale ranges: ±0.5V, ±1V (0V offset, specified 0–10 MHz ±0.2 dB); ±2V and ±5V available with slightly degraded performance
• Reconstruction filter: 3rd order Bessel low-pass (selectable: None, 5 MHz, or 20 MHz)
• Spurious-free dynamic range: 80 dBc minimum (1 MHz); 70 dBc minimum (10 MHz)
• Peak harmonic distortion: 74 dBc maximum (1 MHz, ±0.5V, 0V offset)
• Short-circuit/over-current protection: 10 ms response, ±200 mA minimum

Clocking & Triggering
• Internal clock: 95 Hz to 100 MHz (programmable)
• External clock sources: Front panel connectors, VXI TTL/ECL trigger lines
• Programmable thresholds per module
• Coherent operation across DBS9XX series modules with synchronized timing

– Key Features

• Modular VXI Plug & Play architecture with automatic module recognition
• Independent or simultaneous clocking and triggering of multiple modules
• Flexible waveform memory segmentation for complex signal sequences
• Software drivers include source code and .DLL files for rapid integration

– Typical Applications

• Semiconductor device and circuit testing
• Video and digital communications signal simulation
• Vibration testing and control
• Research and development signal generation

– Compatibility & Integration

Installs in the Analogic DBS9900 “C” size VXI carrier module. Up to two DBS901 modules fit in a single carrier slot. Supports coherent multi-module operation with synchronized clock distribution and minimal skew.
