Ando AQ 8202-32p Attn module FC/LC

The Ando AQ 8202-32p is a precision optical attenuator module designed for integration into Ando test mainframes. It delivers stable, repeatable attenuation across a wide wavelength band, enabling accurate fiber optic signal calibration and component characterization in telecommunications and R&D laboratories.

– Technical Specifications

• Model: AQ 8202-32p
• Wavelength Range: 1280–1620 nm
• Maximum Attenuation: 30 dB
• Attenuation Step Resolution: 0.1 dB
• Optical Return Loss: ≥30 dB (1310–1550 nm)
• Maximum Input Power: +20 dBm
• Connector Type: FC/PC

– Key Features

• Fine-grain attenuation control in 0.1 dB increments enables precise signal level adjustment across the C and L bands. High return loss specification ensures minimal signal reflections and measurement integrity. The module accepts input signals up to +20 dBm, accommodating moderate-power optical sources without degradation.

– Typical Applications

• Fiber optic signal calibration and validation
• DWDM component evaluation (MUX, DEMUX, AWG, EDFA)
• Optical system performance testing
• Signal loss simulation in telecommunications networks
• Laboratory characterization of optical subsystems

– Compatibility & Integration

The AQ 8202-32p integrates with Ando AQ8202, AQ8203, and AQ8204 mainframes as part of the AQ8200 Series modular optical test platform. This architecture supports mixed module configurations including light sources, power meters, and optical switches, enabling flexible multi-parameter test setups.
