Ando AQ4215 1310nm LED Optical Source Module

The Ando AQ4215 is a 1310nm LED optical source module engineered for precision optical measurements in telecommunications and research applications. It generates a stable optical signal at 1310nm for testing and validating fiber optic systems, delivering -21 dBm or greater output across a 140nm or narrower spectral halfwidth. The module integrates into compatible Ando main frames—such as the AQ2140 Optical Multimeter—to form a complete measurement system. Its compact design supports both graded-index and single-mode fiber configurations.

– Technical Specifications

• Emission wavelength: 1310 nm ± 30 nm
• Spectral halfwidth: 140 nm or less
• Optical output level: -21 dBm or more
• Applicable fiber types: GI/SM
• Module model: Ando AQ4215 (131)

– Key Features

• LED source optimized for 1310nm telecommunications band testing
• High-accuracy optical signal generation for spectral component analysis
• Compact form factor for systems integration
• Requires main frame power supply and control electronics
• Optical connectors sold separately (FC, SC, ST, DIN, HMS-10/A adapters available)

– Typical Applications

• Fiber optic system validation at 1310nm
• Optical network component characterization
• Telecommunications equipment testing
• Research and development of optical systems

– Compatibility & Integration

The AQ4215 module interfaces exclusively with compatible Ando main frames, including select AQ2140 Optical Multimeter units. Software version verification is required for certain AQ2140 models to ensure proper operation. Optical return loss measurement is not supported with this LED module. All optical interface connectors and fiber cords are purchased separately.
