The Ando AQ5520 is an optical spectrum analyzer engineered for precise measurement and analysis of optical signals in communications, research, and production environments. This benchtop instrument delivers high-accuracy spectral analysis across diverse optical signal types, including wavelength-division multiplexed (WDM) systems. The AQ5520 combines high resolution and sensitivity to distinguish closely spaced spectral components and measure low-level optical signals, making it essential for advanced optical testing, network analysis, and manufacturing quality control.
– Technical Specifications
• Device Type: Optical Spectrum Analyzer
• Manufacturer: Ando (Yokogawa)
• Model: AQ5520
• Measurement Capability: Precise optical signal analysis across spectral range
• Resolution: High resolution for closely spaced spectral components
• Sensitivity: High sensitivity for low-level optical signal detection
• Accuracy: Wavelength accuracy within ±0.3 dB; polarization dependency ±0.05 dB
• Dynamic Range: Wide dynamic range for signals with varying power levels
– Key Features
• High-accuracy spectral measurement and analysis
• Efficient operation in laboratory and production settings
• Support for WDM system analysis
• High sensitivity signal detection
• Broad optical spectrum analysis capability
– Typical Applications
• Optical communication systems analysis
• Research and development testing
• Optical network characterization
• Manufacturing and production testing
• WDM signal verification
– Compatibility & Integration
The AQ5520 is a standalone benchtop instrument suitable for integration into optical testing environments. Standard AC power operation supports deployment in laboratory and field locations.
