Anritsu 42N50-20 – DC-18GHz N(m-f) Attenuator, 20dB, 5 Watt

The Anritsu 42N50-20 is a fixed coaxial attenuator that reduces RF signal levels across DC to 18 GHz with 20 dB of attenuation. Rated for 5 Watts maximum input power, this 50 Ohm attenuator features N-type connectors (male input, female output) and operates bidirectionally, allowing flexible integration into test systems regardless of signal direction. Built for durability and stable attenuation performance, the 42N50-20 serves laboratory and field measurement applications where precise signal control is required.

## Technical Specifications

• **Attenuation:** 20 dB
• **Frequency Range:** DC to 18 GHz
• **Maximum Input Power:** 5 Watts
• **Characteristic Impedance:** 50 Ohms
• **Connectors:** N-type (male input, female output)

## Key Features

• Bidirectional operation — function in either signal direction without reconfiguration
• Wide frequency coverage from DC through 18 GHz microwave bands
• High power handling at 5 Watts input rating
• Rugged mechanical construction for field and bench use
• Standard 50 Ohm impedance matching for consistent system integration

## Typical Applications

• RF power measurement and control in test racks
• Signal level normalization prior to sensitive instrumentation
• Broadband attenuation across microwave frequencies
• Laboratory characterization and troubleshooting

## Compatibility & Integration

The 42N50-20 integrates with Anritsu Site Master analyzers equipped with the optional power monitor (Option 5), enabling inline power measurement and system validation during field deployments and bench measurements.
