Anritsu S331D Site Master Cable/Antenna Analyzer 4GHz

The Anritsu S331D Site Master is a handheld cable and antenna analyzer designed for field technicians involved in the installation, maintenance, and troubleshooting of wireless communication systems. It operates within a frequency range of 25 MHz to 4 GHz, with optional extensions to 2 MHz (Option 2) and 6 GHz (Option 16). This instrument is engineered to ensure optimal performance of cable and antenna systems, thereby reducing network downtime and enhancing overall reliability.

### Technical Specifications

**General Characteristics**
* **Weight:** Less than 2.28 kg (5 lbs) with battery
* **Dimensions:** 25.4 cm x 17.8 cm x 6.1 cm (10.0 in x 7.0 in x 2.4 in)
* **Power Supply:** Internal NiMH battery (10.8 V, 1800 mAh); External DC input (12.5 to 15 VDC, 3 A max)
* **Operating Temperature:** -10°C to 55°C
* **Environmental:** MIL-PRF-28800F Class 2
* **Display:** TFT color LCD with adjustable backlight, viewable in direct sunlight
* **Languages Supported:** Chinese, English, French, German, Japanese, Spanish

**Measurement Capabilities**
* **Frequency Range:** 25 MHz to 4.0 GHz (Standard)
* Option 2: Extends lower frequency range to 2 MHz
* Option 16: Extends upper frequency range to 6 GHz
* **Output Power:** 0 dBm typical
* **Sweep Speed:** ≤ 2.5 msec / data point (CW ON) or ≤ 3.5 msec / data point (CW ON)
* **Number of Data Points:** 130, 259, or 517 for optimal resolution

**Key Measurements**
* **Return Loss/VSWR:**
* Range: 0.00 to 60.00 dB (Return Loss); 1.00 to 65.00 (VSWR)
* Resolution: 0.01 dB (Return Loss); 0.01 (VSWR)
* Corrected Directivity: >42 dB after calibration
* **Cable Loss:**
* Range: 0.00 to 30.00 dB
* Resolution: 0.01 dB
* **Distance-to-Fault (DTF):**
* Vertical Range: Return Loss (0.00 to 60.00 dB) or VSWR (1.00 to 65.00)
* Horizontal Range: Up to 1497m (4912 ft) or 1197m (3929 ft), dependent on data points and resolution.
* Horizontal Resolution (Rectangular Windowing): Calculated based on cable’s relative propagation velocity (Vp) and frequency span (DF).
* **Radiated Power:** (Requires optional Power Meter or Power Monitor options)
* **T1/E1 Flux Measurements:** (Requires Option 50)

**Optional Capabilities**
* **Option 2:** Extends frequency range to 2 MHz
* **Option 5:** Power Monitor with external measuring detector
* **Option 16:** Extends frequency range to 6 GHz
* **Option 19:** High Accuracy Power Meter (requires external sensor like PSN50 or MA24104A)
* **Option 29:** Integrated Power Meter (no external detector required)
* **Option 31:** GPS Receiver
* **Option 50:** T1/E1 Analyzer
* **InstaCal™ Calibration Module:** Simplifies and speeds up calibration (e.g., reduces calibration time by up to 50%). Directivity of 38 dB for the InstaCal module.
* **FlexCal™:** Broadband calibration feature using OSL method.
* **AM/FM Demodulator:** For testing and troubleshooting wireless communication systems, includes internal speaker and jack.

**Interfaces**
* **RF Out/In:** Type N, female, 50Ω
* **Maximum Input (without damage):** +43 dBm (peak), ±50 VDC (RF In); +23 dBm (RF Out)
* **T1/E1 Interface:** Bantam Jack (S331D Models with Option 50 only)
* **Serial Interface:** RS-232, 9-pin D-sub, three-wire serial
