The Anritsu SM5559 is a portable, handheld antenna and cable analyzer engineered for field technicians to perform VSWR, reflection, and cable loss measurements in wireless infrastructure and RF system installations. Built with a synthesized signal source and graphical display capabilities, it delivers accurate site verification and troubleshooting in a compact form factor. The backlit LCD operates effectively in low-light field environments, while internal memory stores measurement data for later analysis and downloading via PC connection.
– Technical Specifications
Measurement Capabilities
• VSWR (Voltage Standing Wave Ratio)
• Return Loss (RL)
• Cable Loss
• Distance-to-Fault (DTF) measurements—both DTF Return Loss and DTF VSWR
• 1-Port Phase
• 2-Port Gain and 2-Port Phase (with optional accessories)
• Smith Chart analysis
• Optional Power Monitoring
Signal Source & Display
• Built-in synthesized signal source
• Backlit Liquid Crystal Display (LCD)
• Frequency markers and limit line functionality with audible alert when limits are exceeded
Power & Battery
• Field-replaceable battery with up to 2.5 hours continuous operation
• 12.5 Vdc external power source operation
• Energy conservation features to extend battery life
Data Management
• Internal measurement storage
• PC-based Site Master Software Tools for data analysis, scaling, trace enhancement, and marker/limit line management
• Historical graph overlay capability
• Data export for spreadsheet and analytical applications
• Serial cable (null-modem) connection to Windows 95/98/NT workstations
– Key Features
• Keypad-based data entry and menu navigation
• Calibration required before measurements; re-calibration needed if temperature exceeds calibration range or test port extension cable is replaced
• Handheld design optimized for field deployment
– Typical Applications
• Wireless infrastructure installation and maintenance
• RF system verification and troubleshooting
• Cable integrity assessment
• Antenna performance validation
– Compatibility & Integration
Download and analyze measurements using Site Master Software Tools on Microsoft Windows 95/98/NT platforms via null-modem serial connection. Optional accessories include Pelican carrying case, user guide, power cable, carrying bag, and interface cable.
