The Artesyn LPT63 is a 60 W open-frame AC-to-DC power supply engineered for ITE and industrial applications requiring compact integration. Operating from universal AC input (85–264 VAC, 47–440 Hz) or DC input (120–300 VDC or 120–370 VDC), the unit delivers three regulated outputs: 5 VDC primary, +15 VDC, and −15 VDC auxiliary rails. The 3″ × 5″ footprint accommodates space-constrained designs while maintaining 70% typical efficiency at full load.
## Technical Specifications
**Input Power**
• AC Input: 85–264 VAC, 47–440 Hz; max 1.5 A RMS @ 115 VAC
• DC Input: 120–300 VDC or 120–370 VDC
• Inrush Current: <18 A peak @ 115 VAC; <36 A peak @ 230 VAC (cold start, 25 °C)
• Hold-up Time: 20 ms @ 40–60 W load, 115 VAC nominal
**Output Power & Voltage Regulation**
• Convection Cooling: 60 W (5V @ 7 A, +15V @ 2.8 A, −15V @ 0.7 A)
• Forced Air (30 CFM): 80 W (5V @ 8 A, +15V @ 3.3 A, −15V @ 1 A)
• Voltage Regulation: 5V ±2%; ±15V ±5%
• Ripple (peak-to-peak): 5V 50 mV; ±15V 150 mV
• Main Output Adjustment: −5% to +10%; overvoltage protection set 5.7–6.7 VDC
**Safety & Protection**
• Certifications: CB, CE, cULus, cURus; suitable for medical device integration
• Short-Circuit Protection: All outputs
• Overload Protection: 110–145% above peak rating
• Reverse Connection Protection: Yes
• Safety Ground Leakage: <0.5 mA @ 50/60 Hz, 264 VAC; <75 μA max @ 50/60 Hz, 264 VAC input
## Key Features
• Remote sense input compensates for minimum 0.5 V lead drop; operates without remote sense connected
• Peak load ratings: 5V 10 A, +15V 4 A, −15V 1.5 A
• Standard Molex connectors: AC input 09-50-8031, DC output 09-50-8061
• Supports both convection and forced-air cooling configurations
## Typical Applications
Information Technology Equipment, industrial control systems, and OEM integration requiring multi-rail DC power distribution with compact footprint and medical-grade safety approvals.
## Compatibility & Integration
Designed for professional installer and OEM integration into larger systems. Not suitable for standalone operation.
