The Bel Fuse/Power-One HTAA-16W-A is a linear DC power supply designed for a variety of industrial and medical applications requiring low noise and ripple. It offers worldwide AC input capabilities and stable DC output voltages with high regulation. This power supply is suitable for powering sensitive electronic devices and systems due to its robust design and reliable performance.
### Technical Specifications
**General**
* **Manufacturer:** Bel Fuse / Power-One
* **Model:** HTAA-16W-A
* **Product Family:** International Series
* **Type:** Linear DC Power Supply
* **Configuration:** Open-Frame
* **Standards:** UL Listed, CSA Certified, CE Marked to the Low Voltage Directive (LVD), TÜV Approved
* **RoHS Compliant:** RoHS Compatible for All Six Substances
**Electrical**
* **Input Voltage Range:** 100-264 VAC (Also specified as 87-264 VAC and 100/120/220/230/240 VAC)
* **Input Frequency:** 47 to 63 Hz
* **Output Power:** 20 W (One source specifies 17W)
* **Output Regulation (Line & Load):** ±0.05%
* **Low Output Ripple:** Yes
* **Mean Time Before Failure (MTBF):** In Excess of 300,000 Hours
* **Burn-In:** 100% Burn-In
* **Response Time:** 50 µs (Max.)
**Outputs**
* **Number of Outputs:** 3
* **Output Configuration:** Triple Output
* **Output Voltages:**
* Channel 1: +5 VDC
* Channel 2: +12 VDC
* Channel 3: -12 VDC
* **Output Currents:**
* Channel 1: 2 A
* Channel 2: 400 mA (0.4 A)
* Channel 3: 400 mA (0.4 A)
* **Adjustable Output:** Yes
**Overvoltage Protection (OVP)**
* **Feature:** Selectability on most models; standard on 5V single outputs, optional for other outputs under 48V
* **Setting:** Set at 6.2 V ±0.4 V (Note: OVP modules are user adjustable from 6.4V to 34V)
**Interfaces**
* **Remote Sense:** Yes
* **Output Inhibit:** Yes (Available on some configurations, refer to specific model features)
* **Parallel Operation:** Master/Slave capability (Available on some configurations, refer to specific model features)
**Physical**
* **Mounting Type:** Panel Mount, Chassis Mount
* **Case Type:** AA
* **Dimensions:** 6.50″ L x 4.00″ W x 2.10″ H (165.1mm x 101.6mm x 53.3mm) (Note: Case size “AA” dimensions also listed as 7.00 x 4.87 x 3.28 inches)
* **Weight:** 2.513 lbs (Also listed as 2.31 lbs and 2.70 lbs)
**Compatibility**
* **Applications:** Industrial and medical applications needing low noise/ripple (amplifiers, acoustic, broadcast, ATE, and control equipment)
* **ITE (Commercial):** Yes
**Certifications**
* **Agency Approvals:** UL, CSA, TÜV
* **CE Marked:** Yes, to Low Voltage Directive (LVD)
