BK Precision 1635 DC Power Supply

The BK Precision 1635 is a DC power supply designed for general-purpose laboratory and industrial applications. It offers a continuously variable output voltage from 0 to 30 VDC and a current output adjustable from 0 to 3 A. The unit features a 3-1/2 digit LED display for monitoring output voltage, output current, or an external DC voltage up to 199.9 V. It incorporates a pre-regulator for reduced internal power dissipation and improved reliability, along with overload and reverse polarity protection. The power supply operates in either constant voltage (CV) or constant current (CC) modes, with automatic and smooth crossover between them.

### Technical Specifications

* **Model:** BK Precision 1635
* **Manufacturer:** BK Precision (Dynascan Corporation)
* **Type:** DC Power Supply

### Electrical Specifications

* **Output Voltage:** 0 to 30 VDC, continuously adjustable with coarse and fine controls.
* **Output Current:** 0 to 3 A, continuously adjustable with coarse and fine controls.
* **Power Output:** Up to 90 W (calculated based on max voltage and current: 30V * 3A = 90W)
* **Voltage Regulation:**
* Line (110-130 V): ≤ 0.02% + 2 mV
* Load (no load to full load): ≤ 0.02% + 3 mV
* **Current Regulation:**
* Line (110-130 V): < 5 mA typical, 9 mA max * Load (5% to 100% of output current): < 5 mA typical, 9 mA max * **Ripple Voltage:** * Peak-to-Peak: < 2 mV * RMS: ≤ 1 mV * **Current Ripple:** < 3 mA typical * **Temperature Coefficient:** 5 mV/°C typical (0° to +35° C) * **Constant Current (CC) Mode:** Adjustable current limit from 5% to 100% of maximum output current. * **Constant Voltage (CV) Mode:** Adjustable voltage. * **Crossover:** Automatic and smooth crossover between CV and CC modes.### Metering and Display* **Display Type:** 3-1/2 digit LED display (0.5" high digits) * **Display Functions:** Monitors output voltage, output current, or external DC voltage. * **External Voltmeter Function:** Front panel input jacks allow measurement of external DC voltages up to 199.9 V. * **Resolution:** 0.1 volt or 0.1 amp. * **Indicators:** * CV (Constant Voltage) Indicator: Green LED. * CC (Constant Current) Indicator: Red LED. * V (Volt Meter) Indicator: Green LED. * A (Current Meter) Indicator: Red LED.### Protection Features* **Overload Protection:** Fully adjustable current limiting (from 5% to 100% of maximum output current). * **Reverse Polarity Protection:** Prevents damage to the power supply from external reverse polarity voltage.### Electrical Input* **Power Requirements:** 110/120/220/240 VAC ±10%, 50/60 Hz. Selectable via a rear panel switch. * **Power Consumption:** Approximately 175 W or less at full load.### Physical Characteristics* **Styling:** Modern, functional styling designed to conserve bench space and aid portability. * **Dimensions:** Not explicitly stated in provided documentation, but described as conserving bench space. * **Weight:** Not explicitly stated in provided documentation.### Interfaces* **Output Terminals:** Standard output terminals (specific type not detailed). * **External Voltmeter Input:** Front panel jacks. * **AC Power Input:** Rear panel power cord connection.### Compatibility* **Applications:** General electronics servicing, electronics manufacturing, electronics design labs, electronics education, battery charging.### Controls and Indicators* **Voltage Controls:** Coarse and Fine adjustment for output voltage. * **Current Controls:** Coarse and Fine adjustment for current limit in CV mode, and for constant current value in CC mode. * **Pushbutton Assembly:** Three-station pushbutton for selecting meter display function (Volts, Amps, External Volts). * **ON-OFF Switch:** Power control.Why Choose Aumictech for BK Precision 1635? At Aumictech, we specialize in supplying high-end electronic test and measurement equipment. Whether you need reliable DC power for critical applications, precise voltage and current regulation, or versatile external voltage measurement capabilities, our team ensures the BK Precision 1635 delivers maximum performance for your application.
