California Instruments 751TPM AC Power Source

The California Instruments 751TPM is a programmable AC power source designed for simulating a wide range of AC power conditions. This instrument is suitable for product testing, research and development, and quality control applications, offering a blend of functionality and performance for engineers and system integrators.

### Technical Specifications

**Output Power:**
* 750 VA

**Output Voltage Ranges:**
* 0-130 VAC RMS and 0-260 VAC RMS (selectable via rear panel straps)
* Dual voltage range: 100 VAC and 200 VAC
* Standard output voltage ranges: 150 VAC and 300 VAC RMS

**Output Frequency:**
* 45 Hz to 5 kHz
* 20 Hz to 20 kHz
* Up to 1000 Hz (at up to 150 VRMS)

**Output Current:**
* **Low Range:** 7.5 A (RMS) at 100 VAC; 3.75 A (RMS) at 200 VAC
* **High Range:** 3.75 A (RMS) at 200 VAC; 1.88 A (RMS) at 400 VAC
* 10-40 A

**DC Output (if applicable to the model series):**
* **Voltage:** 0-250 VDC (Low Range), 0-500 VDC (High Range)
* **Current:** 6.0 ADC (Low Range) at 125 VDC; 3.0 ADC (Low Range) at 250 VDC
* **Current:** 3.0 ADC (High Range) at 250 VDC; 1.5 ADC (High Range) at 500 VDC

**Electrical Specifications:**
* **Total Harmonic Distortion:** Less than 0.30% from 200 Hz to 600 Hz; less than 0.5% from 45 Hz to 5 kHz
* **Load Regulation:** ±1% over the range from 45 Hz to 5 kHz at unity power factor
* **Frequency Response:** ±0.5 dB from 45 Hz to 5 kHz
* **Power Factor Capability:** Up to ±0.7 PF

**Harmonic Measurements (iX models):**
* Harmonic measurement specifications apply to iX model AC sources.
* **Frequency fundamental:** 16.00 Hz – 81.91 Hz (0.1% accuracy), 82.0 – 819.1 Hz (0.1% accuracy), > 819.1 Hz (0.1% accuracy)
* **Frequency harmonics:** 16.00 Hz – 48 kHz (0.5% accuracy)
* **Voltage (Fundamental):** 0 – 400 Volts (0.5% accuracy)
* **Voltage (Harmonic 2-50):** 0.5% + 0.5%/kHz accuracy
* **Current (Fundamental):** 0 – 15 Amps (0.5% accuracy)
* **Current (Harmonic 2-50):** 0.5% + 0.5%/kHz accuracy

### Interfaces

* **Standard:** USB, LAN
* **Optional:** GPIB
* **Remote Programming:** 0-10 V DC input for voltage and frequency programming (optional)

### Physical

* **Enclosure:** 1U rackmount chassis
* **Dimensions:** Occupies 3.5 inches of rack space (2U)

### Features & Capabilities

* **Programmable AC/DC Source:** Capable of AC, DC, and AC+DC output modes.
* **Integrated Power Analyzer:** Combines AC/DC source with a high-performance power analyzer, potentially eliminating the need for external multimeters, harmonic analyzers, and current shunts.
* **Output Transient Generation:** Capable of generating powerful output transients.
* **High Crest Factor Capability:** Supports demanding load conditions.
* **Arbitrary Waveform Generation:** Enables simulation of complex or non-standard waveforms.
* **Line Distortion Simulation (LDS):** Allows for the simulation of input line distortions.
* **Constant Power Mode:** Provides increased current at reduced voltage, enhancing usability for certain applications.
* **Auto-Paralleling:** For higher power configurations, multiple units can be paralleled.
* **Intuitive Control:** Microprocessor-controlled with a front-panel keypad and an analog control knob for parameter adjustments.
* **Harmonic Analysis:** Includes harmonic analysis of Voltage and Current.
