CCS psb3-30024 Power Supply for LED Lighting

The CCS psb3-30024 is a high-capacity analog control unit designed for industrial lighting applications. It offers versatile control methods, including analog, serial (EIA-485), and parallel communication, allowing for flexible integration into various automation and control systems. This unit is engineered for demanding environments and provides robust performance for tasks such as machine vision, quality inspection, and process control where precise light management is critical.

### Technical Specifications

**General**
* **Manufacturer:** CCS Inc. (also listed under Omron Industrial Automation)
* **Model:** psb3-30024
* **Product Type:** Analog Control Unit (Constant Voltage)
* **Conformed Standards:** CE, UKCA, RoHS
* **Operating Temperature:** 0 to 40°C (32 to 104°F)
* **Storage Temperature:** -20 to 60°C (-4 to 140°F)
* **Operating Humidity:** 20 to 85%RH (no condensation)
* **Storage Humidity:** 20 to 85%RH (no condensation)
* **Cooling Method:** Natural air cooling

**Electrical**
* **Input Voltage:** 100 to 240 VAC (±10%-15%)
* **Frequency:** 50/60 Hz
* **Power Consumption:** 410 VA typical
* **Inrush Current:** 40 A typical (from a cold start)
* **Applicable Light Unit Output Rating:** 24 V / 300 W
* **Rated Output Voltage:** 24 VDC
* **Rated Output Current:** Total for 3 channels: 1.1 A (Note: While the unit is listed as 1 channel for output rating, other sources indicate multiple output connectors, and one mentions 3 channels for rated output current. Clarification may be needed based on specific application.)
* **Overcurrent Protection:** Yes, operates at approximately 105-107% of rated current, resettable by cycling power or holding the setting switch
* **Overvoltage Protection:** Yes

**Interfaces**
* **Control Methods:** Analog, Serial (EIA-485), Parallel
* **Analog Input:** Analog voltage (0 V to +5 V)
* **Serial Communication:** EIA-485 communication, command input
* ID Settings: 00 to 03 via ID switch
* Supports multi-drop wiring for up to four units
* Terminating resistance setting via ID switch
* **Parallel Communication:** 8-bit intensity value setting (B0 to B7) and write signal (WR)
* Offers the fastest time for switching between set values
* **Manual Intensity Control:** 256 steps via setting switch, with a function to lock the intensity value by pressing and holding the switch for 2 seconds
* **Output Connectors (Light Unit):**
* 2 x SRCN2A16-7S (Pins 1-3: output (+), Pins 4-6: output (-), Pin 7: NC)
* 2 x ELR-02V
* **External Control Connector:**
* Parallel communications connector (20-pin MIL-C-83503 compliant)
* ON/OFF input connector (10-pin MIL-C-83503 compliant)
* EIA-485 communications/analog input connector (e-CON compliant)
* **Error Detection Display:** “Err” displayed on the digital display
* **Error Detection Output:** Transistor output via external control connector. Normal operation: Open. Overcurrent output detected: Closed. (Also described as photocoupler insulated, open-collector output)

**Physical**
* **Dimensions (W x D x H):** 97 mm x 245 mm x 110 mm
* **Weight:** 2,300g (Note: some sources list weights for different series like PD3/PD4, which can vary from 400g to 1500g. The PSB3-30024 specifically is 2.3kg)
* **Material:** Steel plate (cover: t1.0, chassis: t1.6), N3 leather tone finish
* **Ingress Protection:** Not explicitly stated, but designed for industrial environments.

**Compatibility**
* **Light Unit Output:** Compatible with 24V / 300W Light Units
* **Control:** Supports analog voltage (0-5V), EIA-485 serial, and 8-bit parallel control interfaces.
* **Cables:** Various communication and control cables are available, including EIA-485 communication cables and parallel communication cables.
* **Software:** Sample programs are available for download, facilitating integration and operation
