Cosel ACE300F Modular Power Supply

The Cosel ACE300F is a modular power supply engineered for flexible, configurable multi-output applications. This 300 W platform accommodates up to four output modules, enabling up to twelve isolated outputs through its modular slot architecture. The unit accepts universal single-phase input (AC 85–264 V, 50/60 Hz) with active Power Factor Correction and complies with IEC 61000-3-2 harmonic attenuation requirements.

## Technical Specifications

**Power & Input**
• Maximum output power: 300 W
• Input voltage range: AC 85–264 V, single-phase, 50/60 Hz
• Maximum input current: 4.1 A
• Output current: Up to 4.1 A (total)
• Efficiency: Up to 80%
• Active Power Factor Correction (PFC) included

**Output Configuration**
• Four module slots for flexible output architecture
• Selectable output voltages: 2 V, 3.3 V, 5 V, 7.5 V, 12 V, 15 V, 18 V, 24 V, 34 V, 48 V
• Symmetric outputs: ±5 V, ±12 V, ±15 V, ±24 V
• Dual-output configurations: 5 V/5 V, 5 V/12 V, 5 V/24 V
• Series and parallel connection supported
• Output voltage adjustment available

**Control & Protection**
• Remote ON/OFF control standard
• Alarm circuit output
• Overload protection: Automatic recovery at ≥105% rated current or ≥101% peak current
• Reverse polarity protection supported

**Safety & Compliance**
• Approvals: UL, C-UL, TÜV, CE, UKCA
• Medical safety: IEC 60601-1/EN 60601-1 Ed. 3.1
• ITE or Medical configurations available

**Mechanical**
• M4 fixing positions, 6 mm maximum screw penetration
• Natural convection cooling integrated

## Key Features

• Twelve isolated outputs achievable within single chassis
• Wide input acceptance eliminates need for voltage selector
• Modular design enables field reconfiguration
• Medical-grade safety approvals for critical applications
• Harmonic compliance reduces distribution system stress

## Typical Applications

Medical instrumentation, industrial test equipment, multi-rail embedded systems, laboratory power distribution, and applications requiring isolated dual or triple voltage rails.

## Compatibility & Integration

End-of-life discontinuation is scheduled for October 2025. Complete technical documentation including datasheet, instruction manual, safety approvals, EMC data, and reliability information is available.
