Dickson TM125

The Dickson TM125 is a battery-powered temperature data logger engineered for continuous thermal monitoring across demanding environments. It captures up to 32,000 sample points with ±0.8°F accuracy, delivers visual alarm notification via High/Low LED indicators, and integrates with DicksonWare™ software (v10.0 minimum) for USB-based data retrieval, real-time graphing, and compliance documentation.

## Technical Specifications

• **Temperature Range:** −10 to +176°F (−23 to +80°C) operating; non-condensing environment
• **Internal Sensor Accuracy:** ±0.8°F
• **Resolution:** 0.1°F (0.0–999.9°F); 1°F above 1000°F
• **Sample Interval:** Variable, 1 second to 24 hours in 10-second increments
• **Data Capacity:** 32,000 sample points
• **Display:** 4-digit LCD, TN positive reflective mode
• **Enclosure:** Polycarbonate, wall-mountable via keyhole slots
• **Dimensions:** 4.0″ × 3.0″ × 1.6″ (10.2 cm × 7.7 cm × 3.9 cm)
• **Weight:** 9 oz
• **IP Rating:** IP20
• **Power:** Four AA alkaline batteries; 1-year typical life (6 months at 1-minute intervals)
• **Connectivity:** USB

## Key Features

• High/Low LED alarm with software-configurable thresholds
• Minimum/maximum temperature display with real-time value tracking
• Unit On LED indicator for active logging status
• Delayed start capability for synchronized monitoring campaigns
• Compact, durable construction for field and controlled-environment deployment

## Typical Applications

Quality assurance verification, cold-chain logistics, pharmaceutical storage validation, and regulatory compliance documentation where time-stamped thermal records are required.

## Compatibility & Integration

DicksonWare™ software enables data download, multi-format graphing, Min/Max/Average analysis, export to Microsoft Excel™ and PowerPoint™, and alarm parameter configuration. Real-time monitoring via software is available; continuous monitoring may reduce battery life.
