Dicon PS-12-3-9-13/15-SC/UPC

The Dicon PS-12-3-9-13/15-SC/UPC is a modular optical switch plug-in for integration into DiCon GP700M Mainframes. It houses three independent 1×2 switches, each capable of routing optical signals across two positions. Built on 9/125 µm single-mode fiber, this unit delivers reliable signal switching for telecommunications, data center, and high-bandwidth network applications where low insertion loss and high return loss rejection are critical.

The SC/UPC connector designation specifies SC connectors with Ultra Physical Contact polish. UPC polish provides superior surface finish and back-reflection performance (-55 dB typical) compared to legacy PC variants, ensuring signal integrity across high-speed transmission. SC connectors use a push-pull mechanism with a 2.5 mm ferrule that prevents rotation, maintaining consistent optical performance. Blue housing enables visual differentiation from APC connectors.

## Technical Specifications

• Switch Configuration: 3 independent 1×2 switches
• Fiber Type: Single-mode, 9/125 µm
• Wavelength Range: 1290–1360 nm and 1530–1560 nm
• Connector Type: SC/UPC
• Insertion Loss (typical): 0.6 dB
• Insertion Loss (maximum): 1.0 dB
• Back-Reflection (maximum): −55 dB
• Polarization Dependent Loss @ 1550 nm (maximum): 0.05 dB
• Switching Time (maximum): 135 ms
• Optical Power Handling (maximum): 300 mW
• Repeatability (typical): ±0.01 dB

## Key Features

• Two-position switching per channel for flexible optical routing
• Low insertion loss maintains signal strength across network paths
• High return loss rejection minimizes reflections and crosstalk
• Minimal PDL ensures wavelength-independent performance
• Fast switching response supports dynamic network reconfiguration

## Typical Applications

• Optical signal routing in telecommunications networks
• Data center cross-connect and failover switching
• High-bandwidth network path selection
• Wavelength band switching (O-band and C-band)

## Compatibility & Integration

Designed exclusively for DiCon GP700M Modular Mainframe integration. SC/UPC connectors mate only with SC/UPC interfaces; SC/UPC and SC/APC connectors are not interchangeable and risk damage if mated incorrectly.
