Exfo FG-720-034M 1550, 1625 OTDR

The EXFO FG-720-034M is a dual-wavelength stand-alone remote OTDR unit engineered for testing and monitoring optical fiber networks at 1550 nm and 1625 nm. Deployed as an autonomous Fiber Guardian device, it performs continuous or on-demand diagnostics without requiring external servers or client PCs. The unit delivers dynamic range of 38 dB at 1550 nm and 36 dB at 1625 nm (measured at 3-minute averaging, 20 µs pulse width, SNR of 1), making it well-suited for metro and FTTx network troubleshooting.

## Technical Specifications

• **Wavelengths:** 1550 nm and 1625 nm
• **Dynamic Range:** 38 dB (1550 nm), 36 dB (1625 nm)
• **Dynamic Range Conditions:** 3-minute averaging, 20 µs pulse width, SNR of 1
• **Data Storage:** Up to 80 GB with RAID protection
• **Power Supply:** Dual hot-swappable redundant supplies; AC (100–240 VAC, 50/60 Hz) or DC (–40/–72 VDC)
• **Network Interface:** 10/100/1000 Base-T Ethernet (IPv4 and IPv6); one dedicated local access port
• **Configuration:** DHCP or fixed IP addressing via rear port
• **Dimensions:** 44 mm (H) × 427 mm (W) × 312 mm (D)
• **Weight:** 13 kg
• **Operating Temperature:** 0 °C to 50 °C
• **Certifications:** CE, CSA-UL, RoHS

## Key Features

• Manual unplanned testing with result download
• On-demand fault-triggered testing
• 24/7 monitoring with fault-event logging only
• Scheduled testing at hourly, daily, or weekly intervals
• Remote access via LAN or dial-up using web browser
• SMS alerts, SNMP traps, and email notifications for fault conditions

## Typical Applications

• Metro network fiber diagnostics
• FTTx deployment and troubleshooting
• Critical fiber strand monitoring

## Compatibility & Integration

Integrates with NQMSfiber for centralized network operations, alarm management, reporting, and trouble-ticket handling. Compatible with standard network management systems via SNMP.
