Exfo FOT-922X Automated Loss/Return Loss Test Set

The EXFO FOT-922X Automated Loss/Return Loss Test Set is a portable, integrated instrument that combines multiple optical fiber characterization functions into a single unit. It performs bidirectional loss testing, optical return loss measurement, light sourcing, and power detection—eliminating the need for separate devices in field and laboratory environments. The FOT-922X supports fiber links ranging from traditional systems to high-speed OC-48 and OC-192 networks.

## Technical Specifications

**Automated Bidirectional Loss Testing**
• Measures single-fiber loss bidirectionally at two wavelengths
• Test completion in under 30 seconds
• Reduces operator error and training requirements

**Light Source**
• Dual-wavelength capability: 1310 nm and 1550 nm (1625 nm available in select configurations)
• Single-port transmission of one or two wavelengths simultaneously

**Power Meter**
• Measurement range up to +35 dBm with Ultra-High-Power™ capability
• Detector wavelengths from 780 nm to 1625 nm (configuration-dependent)

**Optical Return Loss (ORL) Testing**
• Optical Continuous Wave Reflectometer (OCWR) method
• Critical for high-data-rate systems sensitive to backreflection effects

**Visual Fault Locator**
• 650 nm integrated VFL
• Fault detection range up to 5 km
• Identifies breaks, bends, faulty connectors, and splice defects

**Data Management**
• Non-volatile storage: 512 fiber records
• RS-232 interface for PC and portable printer connectivity
• Compatible with EXFO ToolBox 6 software for report generation
• Configurable Pass/Fail thresholds per wavelength with alarm indication

## Key Features

• FasTesT™ automated bidirectional loss measurement
• Optional full-duplex digital talk set for remote communication
• Flexible connector compatibility on detector and FasTesT ports
• Single-unit solution reduces field kit complexity

## Typical Applications

• OC-48 and OC-192 system commissioning and maintenance
• Fiber link loss and return loss characterization
• Cable installation acceptance testing
• Fault location and troubleshooting

## Compatibility & Integration

Data export via RS-232 supports integration with EXFO ToolBox 6 for comprehensive documentation and analysis of optical network performance.
