The Exfo FTB-200 is a compact, modular platform for optical layer diagnostics across access, metro, and FTTx networks. Two field-interchangeable module slots enable OTDR, optical loss testing, optical spectrum analysis, and Ethernet/transport layer analysis in a single instrument. The 6.5-inch color TFT touchscreen (640 × 480 pixels) delivers sunlight-readable performance, while Windows CE/Mobile OS and 4-second on-time ensure rapid field deployment. Rugged construction meets GR-196-CORE durability standards with waterproof housing, sealed connections, and resistance to shock, water, dust, and common chemicals. Extended battery life reaches 8 hours on rechargeable Li-Ion cells (3-hour standard recharge). Dimensions of 322 × 197 × 109 mm and 2.2 kg weight support extended field work.
– Technical Specifications
• Platform: Two field-interchangeable module slots; Windows CE/Mobile OS; 4-second on-time
• Display: 6.5-inch (163 mm) color TFT touchscreen, 640 × 480 pixels, enhanced sunlight visibility
• Interfaces: 2× USB 2.0 (USB A main, USB B remote); RJ-45 10/100 Mbit/s and 10/100/1000 Mbit/s; fiber inspection video port; Compact Flash; Bluetooth and Wi-Fi; 3G modem via universal USB angle; VPN (Cisco, Juniper, Checkpoint)
• Storage: 80 MB internal Flash; external USB (1–2 GB optional) and Compact Flash support
• Power: Rechargeable Li-Ion battery, 8 hours OTDR operation; 3-hour recharge (0–35 °C); AC/DC adapter 100–240 VAC 50–60 Hz 2 A max; 24 VDC 90 W output
• Physical: 322 × 197 × 109 mm; 2.2 kg; GR-196-CORE compliant; waterproof, shock/dust/chemical resistant
• Environmental: Operating –5 to 50 °C; storage –40 to 70 °C (battery max 60 °C); 0–95% RH non-condensing
– OTDR Capability
Example module FTB-7200D-12CD-23B supports multimode (850/1300 nm) and singlemode (1310/1550 nm) testing with dynamic range up to 37 dB (1310 nm SM) and 1 m event dead zone.
– Key Features
• Field-interchangeable modules for multi-layer diagnostics
• Sunlight-readable 6.5-inch touchscreen interface
• 8-hour battery life for full-shift field operations
• Integrated Bluetooth, Wi-Fi, and 3G connectivity with VPN support
• GR-196-CORE rugged construction for harsh environments
• Dual Ethernet ports (Fast and Gigabit)
– Typical Applications
Access network commissioning and troubleshooting; metro fiber plant diagnostics; FTTx deployment verification; multi-layer transport testing.
