Exfo MAX-945 Fiber Certifier OLTS; Test Set Kit

The EXFO MAX-945 Fiber Certifier OLTS Test Set Kit is a dual-unit field test platform for Tier 1 fiber certification in data center and enterprise deployments. Each unit features a 7-inch touchscreen and delivers automated bidirectional testing of insertion loss, optical return loss, and fiber length in under 5 seconds across two wavelengths using FasTesT™ technology. The kit includes 100% automated fiber inspection with integrated pass/fail analysis at both terminations, onboard referencing diagnostics to eliminate reference errors and negative loss, and built-in Encircled-Flux compliance for multimode accuracy without external conditioners. Dual units enable concurrent connector certification at opposite fiber ends while maintaining Tier 1 workflow integration. Standards compliance spans TIA-568 and IEEE cabling specifications. All-day field battery life, Wi-Fi/Bluetooth connectivity, and onboard professional PDF reporting consolidate multiple measurements into single industry-standard documents.

## Technical Specifications

• **Testing Capabilities:** Insertion Loss (IL), Optical Return Loss (ORL), Fiber Length Measurement, Bidirectional Testing, Automated Fiber Inspection
• **Test Speed:** Under 5 seconds for two fibers at two wavelengths
• **Single-mode Wavelengths:** 1310 nm, 1550 nm (standard); 1310 nm, 1550 nm, 1625 nm (SM3 models)
• **Multimode Wavelengths:** 850 nm, 1300 nm (selected configurations)
• **IL Measurement Range:** Multimode up to 20 dB; Singlemode Simplex up to 45 dB; Singlemode Duplex up to 50 dB
• **Length Measurement Range:** Multimode up to 20 km; Singlemode up to specified maximum
• **Connectivity:** Integrated Wi-Fi/Bluetooth
• **Display:** 7-inch high-resolution touchscreen
• **Battery:** Full-day field operation

## Key Features

• FasTesT™ automated bidirectional testing engine
• Dual-unit configuration for simultaneous two-end certification
• Built-in Encircled-Flux compliance for multimode testing
• Onboard reference error and negative loss diagnostics
• 100% automated connector inspection with integrated probe option
• Multi-standard certification: TIA-568, IEEE compliance
• Professional PDF reporting with file consolidation
• Internal memory for large test file repositories

## Typical Applications

• Data center fiber acceptance testing and commissioning
• Enterprise network installation verification
• Tier 1 certification workflows for installation contractors
• Field maintenance and network validation by technicians

## Compatibility & Integration

Supports dual-wavelength testing across single-mode and multimode fiber types. Integrates directly into standard Tier 1 certification workflows with automated result compilation and standards-compliant reporting.
