Fluke FTK200 Optical Fiber Test Kit

The Fluke FTK200 Optical Fiber Test Kit delivers optical power and loss measurement across multiple wavelengths for multimode and singlemode fiber verification. The kit pairs the FM150 Fiber Meter with the FS150 Fiber Source to enable loss measurements, continuity checks, and power characterization essential for network installation and maintenance. Measurements display in dBm or µW with 0.01 dB resolution and ±0.25 dB accuracy. Data logging stores up to 500 measurements per wavelength, with serial output and PC integration via included Data-LINK software for reporting and live power stability analysis.

## Technical Specifications

**FM150 Fiber Meter**
• Measurement range: +6 dBm to -50 dBm
• Resolution: 0.01 dB
• Accuracy: ±0.25 dB at 25 °C
• Wavelengths: 850 nm, 1300 nm, 1310 nm, 1550 nm
• Detector: Germanium
• Power units: dBm or µW
• Memory: 500 measurements per wavelength
• Battery: 9V alkaline, up to 30 hours operation
• Auto power-down: ~5 minutes idle
• Operating temperature: 0 °C to +50 °C
• Storage temperature: -30 °C to +60 °C
• Humidity: 0 to 95% RH (non-condensing)
• Dimensions: 3.2 in × 5.8 in × 1.5 in
• Weight: 8.6 oz (244 g)
• Data interface: Serial port with Data-LINK software

**FS150 Fiber Source**
• Wavelengths: 850 nm, 1300 nm
• Output power: -20 dBm nominal (62.5 µm multimode fiber)
• Stability: ±0.2 dB per 8 hours at 20 °C; ±0.1 dB per 8 hours at 25 °C (post 20-minute warm-up)
• Connector: ST
• Battery: 9V alkaline, ~24 hours typical
• Operating temperature: 0 °C to +40 °C
• Humidity: Up to 75% RH at 0 °C to +40 °C
• Dimensions: 4.5 in × 2.5 in × 1.5 in

## Key Features

• Dual-wavelength source for 850 nm and 1300 nm multimode testing
• Loss comparison via stored reference level
• Battery status display with low-battery indicator
• Live data capture for power stability verification
• Report generation through Data-LINK software

## Typical Applications

• Fiber optic network installation and commissioning
• Loss budget verification across multimode and singlemode links
• Field troubleshooting and continuity testing
• Power output characterization from network interface cards and test sources

## Compatibility & Integration

Serial port connectivity enables data upload to PC and output to serial printers. Data-LINK software manages measurement archiving, real-time monitoring, and documentation generation.
