Fluke / Wavetek 1370 12MHz VXI Sweep/Function Generator

The Fluke/Wavetek 1370 is a 12 MHz VXI Sweep/Function Generator engineered for integration into VXI-based automated test systems. It generates stable, precise sine, triangle, square, and DC waveforms across a frequency range of 0.01 Hz to 12 MHz, with output amplitudes up to 20 Vpp into open circuit or 10 mVpp to 10 Vpp into 50Ω termination. The instrument operates in continuous, triggered, gated, and burst modes, supporting external TTL triggering and VXI bus commands. Bi-directional frequency sweep capability—linear or logarithmic—enables dynamic frequency characterization from 0.01 Hz to 12 MHz. Programmable offset control extends to ±10 V, allowing baseline adjustment or DC output level variation. Output protection guards against external overvoltages up to 100 V peak, with error status flagged to the VXI controller. Amplitude resolution reaches 3.5 digits. Full SCPI command compatibility ensures seamless integration into modern automated test environments and VXI chassis configurations.

## Technical Specifications

• **Form Factor:** C Size VXI Module
• **Frequency Range:** 0.01 Hz to 12 MHz
• **Waveforms:** Sine, Triangle, Square, DC Output
• **Output Amplitude:** Up to 20 Vpp (open circuit); 10 mVpp to 10 Vpp (50Ω termination)
• **Amplitude Resolution:** 3.5 digits
• **Programmable Offset:** ±10 V
• **Output Impedance:** 50Ω nominal
• **Output Protection:** 100 V peak overvoltage protection

## Key Features

• Continuous, triggered, gated, and burst signal modes
• Bi-directional frequency sweep with linear or logarithmic characteristics
• TTL trigger input and VXI trigger bus support
• SCPI command programming for automated control

## Compatibility & Integration

• VXIbus system integration
• SCPI (Standard Commands for Programmable Instruments) compatible
• Designed for VXI-based automated test system environments
