Fujikura CT-03 High Precision Fiber Optic Cleaver

The Fujikura CT-03 High Precision Fiber Optic Cleaver delivers consistent, low-loss cleaves for single-mode and multi-mode optical fibers in field and laboratory environments. Built as a rugged, self-contained unit, it minimizes splice loss through precision cleaving and features a rotating circular blade mechanism that extends blade life while maintaining performance repeatability across operator skill levels.

## Technical Specifications

• **Applicable Fiber:** Conventional silica optical fiber, 125 µm bare diameter
• **Coating Diameter Compatibility:** 250 µm, 900 µm, and 0.25–0.9 mm over 125 µm bare fiber
• **Cleaved Length:** 16 mm
• **Fibers per Cycle:** 1
• **V-Grooves:** Two grooves accommodate variable coated fiber diameters
• **Blade Life:** Exceeds 24,000 cleaves per circular blade; 12,000 total cleaves per blade
• **Blade Positions:** 12 positions with 3 height positions and 16 rotating positions
• **Splice Loss Performance:** Less than 0.5 dB

## Key Features

• Rotating circular blade design for extended operational life and consistent cleave quality
• Dual V-groove system supports both standard 250 µm and 900 µm coated fibers, plus custom diameters from 0.25–0.9 mm
• Engineered for reliable performance across single-mode and multi-mode fiber types
• Exceptional ease of use—delivers excellent results independent of operator experience
• Compact form factor suitable for mobile and bench-top deployment

## Typical Applications

• Field installation and splicing operations
• Laboratory fiber preparation and characterization
• Splice loss minimization in both SM and MM networks
• High-volume cleaving where blade longevity reduces consumable costs

## Compatibility & Integration

The CT-03 accepts Fujikura CT-03/04/07/100 blade cartridges. The unit integrates with the AD-03 adapter plate and operates within the broader CT-04B modular platform where applicable, enabling flexible system configurations for diverse fiber management workflows.
