Fujikura CT-06A High-Precision Single Fiber Optic Cleaver

The Fujikura CT-06A is a semi-automatic single-fiber optic cleaver engineered for precise, consistent cleaving of conventional silica optical fibers. Designed for fusion splicing, field terminations, and laboratory environments, this tool delivers repeatable performance with minimal insertion loss through a high-strength CB-05 blade and intuitive single-step operation. A rotating blade mechanism with 16 positions and three height adjustments yields a 48,000-fiber blade life, eliminating manual height adjustment and reducing maintenance overhead.

## Technical Specifications

• **Fiber Type:** Conventional silica optical fiber, single fiber only
• **Bare Fiber Diameter:** 125 μm
• **Coating Diameter Range:** 250 to 900 μm; compatible with 2 mm and 3 mm cord and drop cable using AD-30C adapter plate
• **Cleave Length:** 5 to 20 mm (250 μm coating); 10 to 20 mm (>250 μm coating); 16 mm fixed (AD-30B adapter); 11 mm fixed (AD-30C adapter)
• **Cleave Angle:** 0.5 degrees; 1 degree average
• **Blade:** CB-05 high-strength steel; 48,000 fiber lifespan (1,000 fibers per position × 3 height adjustments × 16 positions)
• **Dimensions:** 113.5 mm (W) × 82 mm (D) × 42 mm (H)
• **Weight:** 225 g
• **Material:** Magnesium alloy

## Key Features

• Semi-automatic operation—blade advances with single cover press
• Rotating blade design eliminates manual height adjustment
• Integrated fiber scrap collector with rotating handle
• Extended blade lifespan through position and height rotation

## Typical Applications

• Fusion splicing operations
• Field terminations and FTTH deployments
• Laboratory fiber preparation
• Mechanical splice and Field Installable Connector preparation

## Compatibility & Integration

Compatible with all Fujikura fusion splicers. Standard package includes AD-10 fiber plate, carrying case CC-31, hexagonal wrench HEX-01, and instruction manual M-CT05-E.
