Fujikura FSM-40S Profile Alignment Fusion Splicer

The Fujikura FSM-40S is a profile alignment fusion splicer designed for precision optical fiber joining in field and laboratory environments. It delivers consistent low-loss splices across single-mode and multi-mode fiber types using automated core and cladding alignment, high-resolution imaging, and integrated heat treatment. Typical splice loss is 0.02 dB for single-mode and 0.01 dB for multi-mode fibers, with splice completion in approximately 9 seconds and heat-shrink protection in 25 seconds.

## Technical Specifications

**Splicing Performance**
• Splice loss: 0.02 dB (SM), 0.01 dB (MM) — typical
• Splice time: ~9 seconds (SM, standard)
• Reheating time: ~25 seconds (60 mm heat-shrinkable sleeve, standard)

**Fiber Specifications**
• Applicable types: Single-mode, multi-mode, dispersion-shifted
• Coating diameter: 100–150 µm
• Cladding diameter: 125 µm
• Cut length: 8–16 mm

**Optical System**
• Magnification: 200× (X and Y axes); 400× (single axis)
• Display: High-resolution color LCD
• Image storage: Integrated memory for splice data and images

**Alignment**
• Method: Profile Alignment System (PAS)
• Operation: Automatic core/cladding alignment

**Power & Battery**
• Power supply: AC adapter or rechargeable Li-ion battery
• Battery capacity: ~200 splice and heat cycles per full charge
• Charging time: ~2.5 hours
• Electrode life: ~3,000 splices

**Environmental**
• Operating temperature: −10°C to +50°C
• Humidity: 0–95% RH (non-condensing)
• Altitude: Up to 5,000 m
• Dimensions: 190 mm (W) × 150 mm (D) × 172 mm (H)
• Weight: ~2.8 kg (with battery)

## Key Features

• Automatic fiber alignment and arc fusion with loss estimation
• Motorized wind cover for field operation protection
• Integrated automatic tube heater for protection sleeve application
• USB interface for firmware updates and data export
• Field-rated durability with dust and water ingress resistance

## Compatibility & Integration

Accepts standard optical fiber spools with 100–150 µm coating diameter. Data export via USB enables integration with field reporting and splice documentation workflows.
