GE / Bently Nevada 330130-085-00-05 3300 XL Standard Extension Cable

The GE / Bently Nevada 330130-085-00-05 is an 8.5 meter standard extension cable engineered to connect Bently Nevada 3300 XL Proximitor sensors to signal conditioning modules within the 3300 XL 8 mm Proximity Transducer System. The cable delivers an output voltage directly proportional to the distance between the probe tip and conductive surface, enabling both static position and dynamic vibration measurements on critical rotating machinery. It complies with API 670 standards and features complete component interchangeability without requiring individual matching or calibration. Backward compatibility with non-XL 3300 series 5 mm and 8 mm transducer components is maintained.

## Technical Specifications

• **Cable Length:** 8.5 m (27.9 ft)
• **Cable Type:** 75-ohm triaxial cable with fluoroethylene propylene (FEP) insulation
• **Resistance:** 7.59 ± 0.50 Ω triad cable; 50 Ω output resistance
• **Connector Type:** Standard coaxial connector with ClickLoc locking mechanism
• **Pull Strength:** 220 N (50 lbf) or 330 N (75 lbf) via patented CableLoc design
• **Weight:** 0.289 kg (289 g)
• **Supply Voltage (Proximitor Sensor):** –17.5 Vdc to –26 Vdc without barriers; –23 Vdc to –26 Vdc with barriers (12 mA maximum)
• **Supply Sensitivity:** Less than 2 mV/V change in output voltage

## Key Features

• ClickLoc connectors require only finger-tight torque and click when fully seated, preventing loosening under vibration
• Patented TipLoc molding ensures robust bonding between probe tip and probe body
• Operation at voltages more positive than –23.5 Vdc results in reduced linear range
• Industrial-grade metal housing for the Proximitor Sensor

## Typical Applications

• Vibration monitoring on rotating machinery
• Shaft position and eccentricity measurement
• Critical machinery condition assessment in compliance with API 670

## Compatibility & Integration

The 330130-085-00-05 integrates directly into the 3300 XL 8 mm Proximity Transducer System and maintains backward compatibility with non-XL 3300 series transducer components (both 5 mm and 8 mm configurations).
