The GE / BHA / PrecipTech Power Guard SQ-300 Quick Disconnect is a microprocessor-based automatic voltage control (AVC) system engineered for electrostatic precipitator (ESP) management in industrial applications. Using advanced computing and sophisticated control algorithms, it delivers precise power regulation to Transformer Rectifier (T/R) sets via Silicon-Controlled Rectifiers (SCR), optimizing dust collection efficiency and reducing power consumption. The system features a backlit LCD screen with scratch-resistant coating and intuitive operating menus accessible at the touch of a button. Housed in anodized aluminum enclosures, the SQ-300 resists ambient environmental conditions and radio frequency interference while maintaining operational reliability.
– Technical Specifications
• Manufacturer: GE / BHA / PrecipTech
• Model: Power Guard SQ-300 (SQ-300, SQ 300, SQ300)
• Control Type: Microprocessor-based automatic voltage control
• Power Control: Silicon-Controlled Rectifiers (SCR)
• T/R Set Compatibility: Single-phase conventional, 3-phase low ripple, or hybrid (switchable via firmware)
• Enclosure: Anodized aluminum
• User Interface: Backlit LCD screen with scratch-resistant coating; easy-to-read help menus and operating screens
• Processor Technology: Intel® microprocessors
– Key Features
• On-line waveform analysis evaluates T/R set efficiency
• Diagnostic screen warns of problems and suggests corrective actions
• Automatic ramp rate restores precipitator to full power after spark events
• Adjustable fast/search ramp rates enable fine-tuned spark response control
• Adjustable background power setting allows specific power level optimization
• Enhanced back corona detection and control improves collection efficiency
• Automated I/E ratio selection optimizes current and voltage parameters
• Advanced spark response algorithm enables rapid recovery from sparks
• Energy management system optimizes power consumption while maintaining opacity limits
– Typical Applications
• Industrial electrostatic precipitator systems requiring automated voltage control
• Facilities requiring precise ESP performance optimization and dust collection efficiency
• Operations prioritizing reduced power consumption and spark management
– Compatibility & Integration
The SQ-300 accepts both single-phase and 3-phase T/R sets with firmware-selectable operation. Quick disconnect design facilitates rapid equipment changes and maintenance operations.
