Honeywell DR450T-1100-00-001-0-E-0111

The Honeywell DR450T-1100-00-001-0-E-0111 is a 12-inch circular chart recorder engineered for industrial process documentation and control. This single-pen, 24-hour rotation instrument prints its own chart on thermal-sensitive paper, eliminating pre-printed inventory requirements and delivering consistent accuracy independent of ambient temperature and humidity. The microprocessor-based design offers field configurability via keyboard with English-language prompts, housed in a NEMA 4X enclosure for demanding plant and factory environments.

## Technical Specifications

• **Chart Diameter:** 12 inches (304.8 mm)
• **Chart Type:** Plain thermal-sensitive paper (self-printing)
• **Pens:** Single pen
• **Chart Rotation:** 24-hour
• **Input Power:** 115 VAC, 60 Hz
• **Enclosure:** NEMA 4X (optional UL approved)
• **Internal Transmitter Supply:** 24 Vdc (supports up to 2 transmitters)
• **Measurement Accuracy:** Thermocouple ranges ±1°F typical; voltage ranges ±0.1% or better; full-scale ±0.15%

## Key Features

• Universal signal inputs: thermocouples (Types B, E, J, K, N, R, S, T, W5W26), Radiamatic, RTDs (100/200/500 Ω platinum, 100RH), voltage (0-10 mV, 10-50 mV, 0-5 V, 0-10 V), and current (4-20 mA)
• Keyboard-selectable input configuration
• Dual digital displays for real-time readability
• Up to 6 fully configurable alarms
• Integral PID controller with Accutune II tuning algorithm
• Configurable control modes: On-Off, PID-A, PID-B, or PD with manual reset
• Control outputs: time proportioning, current or position proportioning, three-position step, simplex or duplex with mixed forms
• Flow totalization with up to 4 totalizers plus grand total print capability
• RS-485 Modbus communications (model-dependent)

## Typical Applications

Temperature monitoring, process variable documentation, flow rate tracking, and industrial process control in manufacturing and plant operations.

## Compatibility & Integration

Wide input signal compatibility supports legacy and modern transducers. Built-in 24 Vdc power supply accommodates field transmitters. RS-485 Modbus interface enables integration into networked control systems on configured variants.
