HP 8116A Pulse / Function Generator, 50 MHZ

The HP 8116A Pulse/Function Generator delivers waveform generation from 1 mHz to 50 MHz in a single instrument, serving pulse and function generation across testing, timing, and characterization applications. Eight waveform types—sine, triangle, ramp, square, pulse, haversine, havertriangle, and DC—are selectable with output amplitude ranging from 10.0 mVpp to 16.0 Vpp into 50 ohms (doubling into high impedance loads). Pulse width spans 10.0 ns to 999 ms with sub-7 ns edge transitions and less than ±5% ±2 mV perturbations. The instrument supports three modulation schemes: frequency modulation (FM) to ±5% deviation with 1 V/1% sensitivity and DC to 20 kHz modulating frequency; amplitude modulation (AM) at ±2.5 V for 100% modulation and DC to 1 MHz modulating frequency; and pulse width modulation (PWM) in pulse mode. Frequency stability is ±2% over 1 hour and ±5% over 24 hours. Jitter performance reaches less than 0.1% plus 100 ps in pulse mode at 50% duty cycle.

– Technical Specifications

• Frequency Range: 1 mHz to 50 MHz
• Output Amplitude: 10.0 mVpp to 16.0 Vpp (50-ohm load); doubles into high impedance
• Output Impedance: 50 ohm ±5%
• Pulse Width: 10.0 ns to 999 ms (3-digit resolution)
• Edge Transitions: Less than 7 ns
• Pulse Perturbations: Less than ±5% ±2 mV
• Duty Cycle: 10% to 90% (2-digit resolution); adjusted to 20–80% above 1 MHz and 50% above 10 MHz
• FM Deviation: ±5% maximum; 1 V for 1% sensitivity; DC to 20 kHz modulating frequency
• AM Modulation: ±2.5 V for 100% modulation; DC to 1 MHz modulating frequency
• Frequency Accuracy: ±3% ±0.3 mHz below 100 kHz; +5% above 100 kHz (pulse mode, 50% duty cycle)
• Jitter: Less than 0.1% plus 100 ps (pulse mode, 50% duty cycle)
• Frequency Stability: ±2% (1 hour); ±5% (24 hours)

– Key Features

• Eight waveform types including sine, triangle, ramp, square, and pulse
• Counted burst mode generates 1 to 1999 cycles with internal (100 ns to 999 ms) or external triggering (up to 40 MHz)
• Logarithmic up sweep across full frequency range; sweep time 10 ms to 500 seconds per decade
• Pulse width modulation in 8 non-overlapping decade ranges with 10:1 maximum width ratio
• Single-cycle mode for trigger, gate, and external burst operation
• Programmable output limiting and complement/disable functions

– Typical Applications

• Pulse and timing measurements
• Modulation testing and characterization
• Frequency sweep and transient analysis
• Burst generation for digital and analog circuits
