HP / Agilent 5364A MICROWAVE MIXER/DETECTOR

The HP/Agilent 5364A is a microwave mixer/detector that performs frequency downconversion and signal detection across the 2 GHz to 18 GHz band. It extends analyzer capabilities to higher microwave frequencies, enabling precise RF signal manipulation and detection in measurement systems requiring detailed signal analysis.

## Technical Specifications

• **RF Input Frequency Range:** 2 GHz to 18 GHz
• **Local Oscillator Input Range:** 2.2 GHz to 18 GHz
• **IF Output Range:** 10 MHz to 500 MHz
• **RF Input Dynamic Range:** 73 dB (pulse signals), 53 dB (CW signals)
• **Video Output Risetime:** Less than 7.5 ns
• **Group Delay:** Less than 1 ns across 500 MHz IF output range

## Key Features

• APC 3.5 (male) connectors for RF and LO inputs
• BNC connectors for IF and video outputs
• Built-in manual attenuator for signal level control
• No internal adjustments or calibration required
• Benchtop or rack-mountable configuration with optional adapter kits

## Typical Applications

• Spectrum analysis in microwave measurement systems
• Signal generation and detection tasks
• Integration with frequency counters and test equipment
• High-frequency signal characterization and analysis

## Compatibility & Integration

Designed for integration into microwave measurement systems alongside spectrum analyzers, frequency counters, and related test instrumentation. Application Note AN 358-1 documents use with the HP 5371A Frequency and Time Interval Analyzer.
