HP / Agilent 6813B Performance AC Power Source, 1750 VA, 300 V, 13 A

The HP/Agilent 6813B is a high-performance AC power source and integrated power analyzer designed for demanding test and evaluation of power supplies, UPS systems, avionics equipment, and power factor corrected devices. This instrument generates and measures AC and DC power across a wide range of voltage and current levels, simulates normal and distorted waveforms, and performs comprehensive harmonic analysis—all within a single integrated platform. The 16-bit precision power analyzer measures RMS voltage and current, real/apparent/reactive power, total harmonic distortion, and harmonic content up to the 50th harmonic. It accepts analog programming via dedicated terminals, GPIB (with optional interface card), and RS-232 communication, with a graphical user interface for non-programmed operation.

## Technical Specifications

**AC Output:**
• Power: 1750 VA
• Voltage (rms): 0–300 V
• Current (rms): 0–13 A
• Maximum Peak Current: 80 A
• Frequency Range: DC + 45 Hz to 1 kHz
• Crest Factor: 6
• Voltage Accuracy (45–100 Hz): 0.15% + 0.3 V
• Voltage Accuracy (>100–500 Hz): 0.5% + 0.3 V
• Voltage Accuracy (>500–1000 Hz): 1% + 0.3 V
• Frequency Accuracy: 0.01% + 10 µHz

**DC Output:**
• Power: 1350 W
• Voltage: ±425 V (AC) / 425 V (DC)
• Current: 10.0 A
• Voltage Accuracy: 0.1% + 0.5 V

## Key Features

• Arbitrary waveform generation with support for AC + DC combined signals
• Triggered acquisition for digitized voltage and current waveforms
• Peak voltage and current measurement
• Harmonic analysis with amplitude and phase up to the 50th harmonic
• Total harmonic distortion measurement for voltage and current
• Safety Class 1 with protective earth terminal
• Operating altitude to 2000 meters; humidity to 95% (non-condensing)

## Typical Applications

• Power supply and UPS testing
• Avionics automatic test equipment and RTCA DO-160 compliance testing (400 Hz nominal)
• Power factor correction device evaluation
• Efficiency measurements and static/dynamic testing

## Compatibility & Integration

Optional GPIB interface card (6813B-82350B PCI High-Performance GPIB Interface Card) for remote control; RS-232 and analog programming terminals standard.
